Architectural Anti Theft Wire Mesh , Home Office Security Wire Mesh
Architectural Anti Theft Wire Mesh , Home Office Security Wire Mesh
Architectural Anti Theft Wire Mesh , Home Office Security Wire Mesh
Architectural Anti Theft Wire Mesh , Home Office Security Wire Mesh
Specifications
Brand Name :
CHENG HE
Model Number :
Q195 Q235 Q275 Q345 SS304 316 304lL 316L
Certification :
ISO9001
Place of Origin :
HE BEI
MOQ :
1KG
Payment Terms :
D/A, L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100T/DAY
Delivery Time :
15-20DAYS
Packaging Details :
in waterproof paper in rolls. Custom packing available at request
Material :
SS304 316 304lL 316L
Name :
635 500 200 100 80 60 40 20Mesh ASTM 304 316 Stainless Seel Plain Weave Wire Mesh
wire diameter :
0.025-2mm
Width :
0.1-2m
Lenght :
100' 50' or your request
Color :
Black / Grey / Ecru, etc.
Description

635 500 200 100 80 60 40 20Mesh ASTM 304 316 Stainless Seel Plain Weave Wire Mesh

Description:

Stainless Steel Woven Wire Mesh and Stainless Steel Woven Wire Cloth are widely used in petroleum, chemical industry, environment protection, mine, airspace, paper-making, electronic, metallurgy, etc.

Special size and specification are available according to customers requirements.

Material for weaving stainless steel wire mesh ( wire cloth ) is divided into Type 302, Type 304, Type 304L, Type 316 and Type 316L.

Stainless Steel Wire Mesh
Material SS304, SS316
Grade 201Cu, 302HQ, 3047HC, 304Cu, 410, 430, etc.
Characteristic

· Strong resistance to impact, anti-theft, bulletproof, anti-mosquitoes, high temperature resistance, flame retardant, high strength, strong toughness;

· The surface luster is bright and beautiful, can be better to increase air circulation rate and the light of the sun, with smooth surface, the number of mesh standard, latitude and longitude curve are consistent;

· Its remarkable characterstic is as hard as iron hard, anti-theft, bulletproof, home office security first place;
Application Architectural decoration

Architectural Anti Theft Wire Mesh , Home Office Security Wire Mesh

Application:


With the above-mentioned features, Stainless Steel welded wire mesh is a good choice for fishery industry, food drying, marine use, rodent proofing, cages for animals, and decoration, etc.

Trade Information

1. Port: FOB SHANGHAI, or CIF & CNF discharging any port
2. MOQ: 30 square meters
3. Delivery time: 7-30 days
4. Packing: waterproof paper or as customers' requirements
5. Shipment: Sea Shipping, Air Freight, DHL
6. Supply capability: 1,000 square meters / month


Stainless Steel Wire Quality:

For stainless steel welded wire mesh, the material quality control is regarded as the vital importance. We have signed Long-term Buying Contract with Chinese best stainless steel wire manufacturer-Taiyuan Stainless Steel Wire Corp, this ensure our stainless steel wire are the top quality in China.

Typical Weaving Patterns for Stainless Steel Wire Mesh: Plain weave, twill weave, dutch weave.

General Use: Stainless steel wire mesh, with its excellent resistance against acid, alkali, heat and corrosion, find extensive uses in processing of oils, chemicals, food, pharmaceuticals, also sorting and screening of solid, liquid and gas in mine, metallurgy, airspace, machine making, etc.

Mesh/Inch Wire Diameter Aperture Open Area Weight(LB) /100 Square Foot
Inch MM Inch MM
1x1 .080 2.03 .920 23.37 84.6 41.1
2X2 .063 1.60 .437 11.10 76.4 51.2
3X3 .054 1.37 .279 7.09 70.1 56.7
4X4 .063 1.60 .187 4.75 56.0 104.8
4X4 .047 1.19 .203 5.16 65.9 57.6
5X5 .041 1.04 .159 4.04 63.2 54.9
6X6 .035 .89 .132 3.35 62.7 48.1
8X8 .028 .71 .097 2.46 60.2 41.1
10X10 .025 .64 .075 1.91 56.3 41.2
10X10 .020 .51 .080 2.03 64.0 26.1
12X12 .023 .584 .060 1.52 51.8 42.2
12X12 .020 .508 .063 1.60 57.2 31.6
14X14 .023 .584 .048 1.22 45.2 49.8
14X14 .020 .508 .051 1.30 51.0 37.2
16X16 .018 .457 .0445 1.13 50.7 34.5
18X18 .017 .432 .0386 .98 48.3 34.8
20X20 .020 .508 .0300 .76 36.0 55.2
20X20 .016 .406 .0340 .86 46.2 34.4
24X24 .014 .356 .0277 .70 44.2 31.8
30X30 .013 .330 .0203 .52 37.1 34.8
30X30 .012 .305 .0213 .54 40.8 29.4
30X30 .009 .229 .0243 .62 53.1 16.1
35X35 .011 .279 .0176 .45 37.9 29.0
40X40 .010 .254 .0150 .38 36.0 27.6
50X50 .009 .229 .0110 .28 30.3 28.4
50X50 .008 .203 .0120 .31 36.0 22.1
60X60 .0075 .191 .0092 .23 30.5 23.7
60X60 .007 .178 .0097 .25 33.9 20.4
70X70 .0065 .165 .0078 .20 29.8 20.8
80X80 .0065 .165 .0060 .15 23.0 23.2
80X80 .0055 .140 .0070 .18 31.4 16.9
90X90 .005 .127 .0061 .16 30.1 15.8
100X100 .0045 .114 .0055 .14 30.3 14.2
100X100 .004 .102 .0060 .15 36.0 11.0
100X100 .0035 .089 .0065 .17 42.3 8.3
110X110 .0040 .1016 .0051 .1295 30.7 12.4
120X120 .0037 .0940 .0064 .1168 30.7 11.6
150X150 .0026 .0660 .0041 .1041 37.4 7.1
160X160 .0025 .0635 .0038 .0965 36.4 5.94
180X180 .0023 .0584 .0033 .0838 34.7 6.7
200X200 .0021 .0533 .0029 .0737 33.6 6.2
250X250 .0016 .0406 .0024 .0610 36.0 4.4
270X270 .0016 .0406 .0021 .0533 32.2 4.7
300X300 .0051 .0381 .0018 .0457 29.7 3.04
325X325 .0014 .0356 .0017 .0432 30.0 4.40
400X400 .0010 .0254 .0015 .370 36.0 3.3
500X500 .0010 .0254 .0010 .0254 25.0 3.8
635X635 .0008 .0203 .0008 .0203 25.0 2.63
Specifications
Type
Mesh/Inch
Wire diameter
(inch)
OPen Area
Weight (LB) /100 Square Foot
Plain,Twill Wire Mesh
1 × 1-635 × 635
0.0008"-0.08"
25 to 84.6
2.53 to 41.1
Type
Mesh/Inch
Wire diameter
(inch)
Absolute Filtration Finess μm
Nominal Filtration Finess μm
Plain Dutch Weave Wire Mesh
8 × 85 - 80 × 400
0.014'' × 0.0126''- 0.0049'' × 0.0028''
318-340 to 43-48
250-255 to 35-40
Twill Duntch Weave Wire Mesh
20 × 250 - 500 × 3200
0.0098'' × 0.0079'' - 0.0015'' × 0.0010''
110-120 to 8-9
98-105 to 2-3
