Durable 2.4 Inch Sunlight Readable TFT LCD Display 240x320 TFT-H024A9QVIFT8N20
Durable 2.4 Inch Sunlight Readable TFT LCD Display 240x320 TFT-H024A9QVIFT8N20
Durable 2.4 Inch Sunlight Readable TFT LCD Display 240x320 TFT-H024A9QVIFT8N20
Durable 2.4 Inch Sunlight Readable TFT LCD Display 240x320 TFT-H024A9QVIFT8N20
Durable 2.4 Inch Sunlight Readable TFT LCD Display 240x320 TFT-H024A9QVIFT8N20
Durable 2.4 Inch Sunlight Readable TFT LCD Display 240x320 TFT-H024A9QVIFT8N20
Durable 2.4 Inch Sunlight Readable TFT LCD Display 240x320 TFT-H024A9QVIFT8N20
Durable 2.4 Inch Sunlight Readable TFT LCD Display 240x320 TFT-H024A9QVIFT8N20
Specifications
Brand Name :
HOTHMI
Model Number :
TFT-H024A9QVIFT8N20
Place of Origin :
dongguan,China
MOQ :
2
Payment Terms :
L/C, D/A, T/T, D/P, Western Union, MoneyGram
Supply Ability :
99999
Delivery Time :
25 days
Product Type :
TFT
Display Content :
240x320
Dimensions (mm) :
42.52x59.86x2.20
Viewport Window Size :
2.4"
Effective Size (mm) :
36.72x48.96
Backlight brightness :
800cd/m2
Description

2.4 inch Sunlight Readable TFT LCD Display/240x320 Pixels/TFT-H024A9QVIFT8N20

Product parameters


Display Size - 2.4"
Product Application - Instrumentation
Perspective - Full Perspective
Connection method PIN number - FPC-20PIN
Interface method - MIPI
Special Instructions - RTP available
Operating temperature - (-20~70℃)
Supply Voltage - 3.2v
Driver chip model - JD9852

Item Standard Value Unit
Display Size 2.4” --
Number of Pixels 240(H)x3(RGB)x320(V) --
Active Area 36.72(H)x48.96(V) mm
Outline Dimension 42.52(H) ×59.86(V)× 3.40(D) mm
Viewing Direction Full O’Clock -
Interface MIPI-1L (Video mode) -
Driver IC JD9852 -
Driver Condition VCI=2.8V,IOVCC=1.8V V
Backlight White LED -
Touch Panel Resistive Touch Panel -
CTP Driver IC - - -
CTP Driver Condition VDD=3.3V
Operation Temperature -20~70 ℃
Storage Temperature -30~80 ℃

TFT-H024A9QVIFT8N20 is a 2.4-inch TFT color LCD screen carefully designed by Xinhongtai HOTLCD R&D team, 240*320 resolution, high picture quality, wide viewing angle, 65K/262K true color, built-in JD9852 controller, support MIPI interface , No peripheral circuit, 20PIN plug-in FPC can be connected to the main board (optional connector), single power supply DC2.8V power supply. This TFT module can be equipped with a touch screen, and all materials comply with the RoHS standard of environmental protection requirements. It is widely used in various instruments, smart devices, analytical instruments, hand-held instruments, driving recorders, etc. : 8051, PIC, AVR, ARDUINO, ARM and Raspberry Pi, etc.

Durable 2.4 Inch Sunlight Readable TFT LCD Display 240x320 TFT-H024A9QVIFT8N20Durable 2.4 Inch Sunlight Readable TFT LCD Display 240x320 TFT-H024A9QVIFT8N20Durable 2.4 Inch Sunlight Readable TFT LCD Display 240x320 TFT-H024A9QVIFT8N20Durable 2.4 Inch Sunlight Readable TFT LCD Display 240x320 TFT-H024A9QVIFT8N20Durable 2.4 Inch Sunlight Readable TFT LCD Display 240x320 TFT-H024A9QVIFT8N20Durable 2.4 Inch Sunlight Readable TFT LCD Display 240x320 TFT-H024A9QVIFT8N20Durable 2.4 Inch Sunlight Readable TFT LCD Display 240x320 TFT-H024A9QVIFT8N20

TFT-H024A9QVIFT8N20_V1.pdf
