Mini Drinking Water Linear Type Split Bottle Filling Machinery Economic
Mini Drinking Water Linear Type Split Bottle Filling Machinery Economic
Mini Drinking Water Linear Type Split Bottle Filling Machinery Economic
Mini Drinking Water Linear Type Split Bottle Filling Machinery Economic
Mini Drinking Water Linear Type Split Bottle Filling Machinery Economic
Mini Drinking Water Linear Type Split Bottle Filling Machinery Economic
Mini Drinking Water Linear Type Split Bottle Filling Machinery Economic
Mini Drinking Water Linear Type Split Bottle Filling Machinery Economic
Specifications
Brand Name :
Ellison
Model Number :
LCGF 12-12-1 / 18-18-4 / 24-24-6
Certification :
CE/ BV / ISO
Place of Origin :
Jiangsu, China
MOQ :
Negotiation
Price :
Negotiated
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
7 sets per month
Delivery Time :
50 working days
Packaging Details :
Standard export wooden case or pallet package
Processing type :
split water fillign machine
Bottle type :
5L plastic bottle
Cap type :
Plastic screw cap
Voltage :
208-460V 3 phase 50-60HZ
Bottle neck :
45mm
Pump :
CNP pump
Control manner :
Solenoid control
HS code :
8422301090
Description

Economic Low Cost Mini Drinking Water Linear Type Split Bottle Filling Machinery

The Semi automatic bottle filling machine is precisely filling all kind of non-carbonated beverage and low thickness beverage such as vitamin water, nutritive water, pure water, mineral water, drink water, mountain spring water etc. It connection bottle washing, filling and capping machine.All parts of the small water bottling machine is made of stainless steel materials, it cannot cause rust to influence the filling beverage, it not only reach the standard of sanitation, but also prolong its using life.
1.No bottle no filling, no bottle no capping, a high degree of automatization and simple human-machine operation display screen.

2.With clamp hanging the bottle neck, the feed speed is very quick and the bottle will not be deformed.
3.Adopting advanced bottleneck technology to wash bottle mouth, it avoids the contact with the thread nipple, which is more sanitary.
4.Adopting bottleneck technology in bottle conveying, there is no need to adjust the height, but only to change the shield related with the bottle diameter.

Bottle Rinsing Machine

Material: 304 Stainless steel
12 bottles are running on the conveyer belt with photo electricity, the bottle cylinder will go out, meanwhile push the bottle into bottle support ring, and bottle neck support catch the bottle neck, than main shaft turned 180degree under gear wheel. Let bottle’s mouth face to land, jetting liquid into bottle, after a few seconds, the main shaft will be back, than finishing the washing.

Specification & technical parameters of CGF Series washing machine
Type CGF-12A
Number of bottles washing 12 bottles
Production capacity 2000-3000B/h
Applicable bottle's diameter ¢56-¢100mm
Bottle's height 160-310mm
Main machine's power 0.75kw
Weight(N/G) 800/850kg
Voltage AC380±5% 50HZ
Outer dimension (mm) 1200*1100*1700
Packing size (mm) 1450*1350*1950

Water Filling Machine

Material: 304 Stainless steel

Washing finished bottle is conveyed into filling position , cylinder push and hold the plate which can hitch bottles , the mouth of bottle can open the valve , finishing filling , plate which can hitching bottle will running down, the valve will closed automatically, the time lasting of filling can be adjusted.

Specification & technical parameters of CGF Series filling machine
Type CGF-12
Number of bottles filling 12 bottles
Production capacity 1500-3000B/h
Bottleneck's inner diameter ¢15-¢25mm
Bottle's body's outer diameter ¢55-¢95mm
Bottle's height 160-310mm
Speed-adjusting electromotor 0.75kw 125-1250r/min
Speed-down electromotor WHT100-50V III
Weight(N/G) N.W:1000Kg G.W:1250Kg
Voltage AC380±5% 50HZ
Outer dimension (mm) 1200*1100*2000
Packing size (mm) 1250*1050*2250

Bottle Capping Machine

Material: 304 Stainless steel
The working is intermission when running. There are six positions for capping, and have 1 capping head, can automatically capping.

Specification & technical parameters of CGF Series sealing machine
Type CGF-1
Number of bottles sealing 1 bottle
Production capacity 1500-3000B/h
Applicable Bottle diameter ¢56-¢100mm
Bottle's height 160-310mm
Theftproof cap's size ¢28×15mm
Weight(N/G) N.W:600Kg G.W:650Kg
Voltage AC380±5% 50HZ
Outer dimension (mm) 930*700*2100
Packing size (mm) 1180*950*2350

NOTE:

Make It Easy To Start Bottled Water Business.

1. Supply Completely Bottled Water Plant Machinery;
2. Supply Bottled Water Materials Like PET Preform, Bottle Cap and Label, Packing Roll PE Film;
3. Bottle Design For Choice, Free Drawing Factory Layout.

4. Oversea Installation.(80 USD Per Day)
