Specifications
Brand Name :
CF
Model Number :
1.2083/420/s1316/4Cr13
Certification :
ISO/TUV/BV
Place of Origin :
China
MOQ :
3MT
Price :
USD1700-2200/MT
Payment Terms :
L/C, T/T
Supply Ability :
1000MT/month in stock
Delivery Time :
15-20days
Packaging Details :
wooden case/customized
Material :
Mould Steel
Workmanship :
Hot Rolled/Forged
Shape Option :
Flat Bar/ round bar/ block/plate
Delivery Condition :
Annealed
Description

Stainless Steel 1.2083/S1316/420/4Cr13 For Plastic Mould

1.2083 mould steel is a kind of plastic mould steel with high chromium element which is up to 13%.
1.2083mould steel has good wear resistance and good polishing, it widely used for acid proof plastic mold.

Similar grade:DIN 1.2083 AISI 420 JIS SUS420J2

1, Features:
1) Excellent corrosion resistance;Excellent abrasion resistance and elasticity;
2) Excellent high-temperature abrasion resistance;
3) Medium toughness,dimensionally stable, high compressive strength;

2, Application:
1) highly stressed cutting and punching tools for thin sheets;
2) stone processing tools and knives for paper and plastics, shear knives
3) Chemical Resistance plastic mold, corrosion of thermoplastic plastics;

Stainless Steel 1.2083 / S1316 / 420 / 4Cr13 Plastic Mold Steel High - Temperature Abrasion Resistance

Stainless Steel 1.2083 / S1316 / 420 / 4Cr13 Plastic Mold Steel High - Temperature Abrasion Resistance




3, Material Grade:S-STAR

Comparable Standard AISI JIS W.Nr
420 Modified ESR SUS420J2 Modified ESR 1.2083 Modified ESR


4, Chemical composition(%)

C Si Mn Cr S V
0.34-0.42 0.6-1.3 0.20-0.70 13.0-14.50 0.03



5, Package:We provide standard export packing or according to customers' request.

8, Delivery:For abundant stock, 15-20 days.For customized products, 30-50 days.

9, Heat Treatment:

Annealing : 810 - 830 °C
Hardness after annealing : Max.230 HB
Stress relieving: Approx.650 °C
Hot forming: 1050 - 850 °C
Hardening: 970 - 990 °C
Quenching media: Oil, Vacuum
Hardness after quenching: 52 - 56 HRC



10, Hardness after tempering:

Tempering °C
100
200
300
400

HRC
54
52
52
52
