1.2312/P20+S Alloy Steel Plate For Precision Plastic Mold With Thickness 16-125mm
1.2312/P20+S Alloy Steel Plate For Precision Plastic Mold With Thickness 16-125mm
1.2312/P20+S Alloy Steel Plate For Precision Plastic Mold With Thickness 16-125mm
1.2312/P20+S Alloy Steel Plate For Precision Plastic Mold With Thickness 16-125mm
Specifications
Brand Name :
Changfeng
Model Number :
1.2312/P20+S
Certification :
ISO/ Mill Certificate
Place of Origin :
China
MOQ :
3T
Price :
950-1300USD/T
Payment Terms :
T/T, L/C
Supply Ability :
1000t/Mouth
Delivery Time :
15-20 days
Packaging Details :
bulk packing
Technique :
Hot Rolled,Forged
Surface treatment :
black or machined
Length :
2000-8000MM
Application :
mould steel
Grade :
1.2312/P20+S
Width :
2000-2200MM
Type :
Steel Plate
Description

1.2312/P20+S Alloy Steel Plate for Precision Plastic Mold with thickness 16-125mm


1. Features
a. uniform hardness qualitative of Material;
b. No quenching crack danger,Without heat treatment costs that can reduce the tool cost;
c. Excellent polishing performance;
d. Good machining performance;

2. Application:
Mainly used for the degree of thefamily which do not require extreme large plastic moulds, Used as a low melting point of die holder , mould base, etc.

3. Grade

W.Nr DIN AFNOR AISI/SAE GB
1.2312 X40CrMnMoS8-6 (40CMD8S) P20+S 4Cr2MnMo


4. Chemical composition (%)

C Mn Si Cr Mo S P
0.35-0.45 1.40-1.60 0.30-0.50 1.80-2.10 0.15-0.25 0.05-0.10 ≤0.030


5. Phase transition temperature

Ac1 740°C
Ms 310°C


6. The hardness of delivery

Prehardened and tempered HB278-325(950-1100N/mm²)


7. Heat treatment

Annealing 1)Heated to720-750°C,Two to four hours heat preservation,
2)Furnace cooling
Stress relief 1)Heated to560-650°C and then two to four hours heat preservation
2)Furnace cooling or air cooling
Pre hardened 1)Preheat to 600-650°C
2)Heated to hardening temperature 840-840°C and heat preservation
3)Oil cooling
4)Hardness:HRC51
Drawing temper 1)Immediately after quenching
2)When the 580-650°C,with the 1/inch to heat preservation


8. Delivery: For abundant stock, 15-20 days.For customized products, 30-50 days.

9. Packing: We provide standard export packing or according to customers' request.

Hot sale products for hot/cold work mould Steel
STANDARD/GRADE Flat Bar Size(mm) Round bar Size(mm) Technics
DIN AISM JIS GB(China) Thickness Width Length Diameter Length
1.2311 P20 PDS-3 3Cr2Mo 10-700 155-2200 2000-6000 20-200 2000-6000 Forged,
Hot Rolled
1.2738 P20+Ni - 3Cr2NiMnMo 10-1100 155-2200 2000-6000 20-200 2000-6000
1.2379 D2 SKD10 SKD10 10-200 155-810 2000-6000 20-200 3000-6000
1.2080 D3 SKD1 3Cr2Mo 10-200 155-810 2000-6000 20-200 3000-6000
1.2083 420 - 4Cr13 10-500 155-1200 2000-6000 20-300 3000-6000
1.2344 H13 SKD61 4Cr5MoSiV1 10-500 155-1600 2000-6000 20-400 3000-6000
1.2510 O1 SKS3 9CrWMn 10-200 155-810 2000-6000 20-200 3000-6000
1.7225 SAE4140 SCM440 42CrMo 10-200 155-2200 2000-6000 20-200 3000-6000
1.2010 SAE1050 S50C 50# 10-700 155-2200 3000-6000 10-300 3000-6000 Hot Rolled
1.1191 SAE1045 S45C 45# 10-700 155-2200 3000-6000 10-300 3000-6000
