DIN 1.2738 718 P20+Ni Prehardened Special Steel Flat Bar For Making Injection Mold
DIN 1.2738 718 P20+Ni Prehardened Special Steel Flat Bar For Making Injection Mold
DIN 1.2738 718 P20+Ni Prehardened Special Steel Flat Bar For Making Injection Mold
DIN 1.2738 718 P20+Ni Prehardened Special Steel Flat Bar For Making Injection Mold
Specifications
Brand Name :
Changfeng
Model Number :
1.2738/P20+Ni/3Cr2NiMnMo
Certification :
ISO/ Mill Certificate
Place of Origin :
China
MOQ :
3T
Price :
1275-1360usd/sqm
Payment Terms :
T/T, L/C
Supply Ability :
1000 ton/Month
Delivery Time :
15-20 days
Packaging Details :
bulk packing
Shape :
Block
Process Technology :
Annealed/Forged
Heat Treatment :
Annealed / Q+T
Quality Inspection :
100% UT passed
Thickness :
300-810mm
Description

1.2738 718 P20+Ni Prehardened special Steel flat Bar For Making injection mold

1.2738 718 P20+Ni Prehardened special Steel flat Bar For Making injection mold

DIN 1.2738, forged Plastic Mould Steels, pre-hardened large size injection mould, can be pollished normally.Used for making high demand large size plastic mould.

1. Features
A. uniform hardness qualitative of Material;
B. No quenching crack danger,Without heat treatment costs that can reduce the tool cost;
C. Excellent polishing performance;
D. Good machining performance;

2. Application
Used for various large -sized mirror plastic mould,percision mould;
A. Leather grain, pear skin grain etching, imitation stone moulds;
B. Clear plastic container classes such as pencil case, commodity high gloss mould;
C. Such as refrigerator, air conditioner production to demand higher large mould;

3. Grade

GB AISI DIN
3Cr2NiMnMo P20+Ni 1.2738


4. Chemical composition(%)

C Mn Si Cr Ni Mo P S
0.35-0.45 1.30-1.60 0.20-0.40 1.80-2.10 0.90-1.20 0.15-0.25 ≤0.035 ≤0.035


5. Mechanical Properties:

Hardness Y.S.(0.2%) UTS Elongation RoA Elastic Modulus
HB Mpa KSI Mpa KSI % Z% GPA KSI
300 826 120 993 145 17 59 205 29745


6. Hardness:33-37HRC

7. Packing:Standard Export Packing or As per request

8. Delivery:
Abundant stock, 15-20 days.
Customized products, 30-50 days.

Package: We provide standard export packing or according to customers' request.

All the sizes as require can be customerized as fresh production with MOQ,products of required specifications can be developed/produced per international, chinese or industry standards, or based on agreements with customers.

9. The process flow
1) Hot rolled or forged condition, Pre-harden &tempering , black surface
2) Hardness:30~36HRC
3) Hot rolled technology:EAF+LF+VD
Forged technology:EAF+LF+VD+ESR+Forging +QT + Machined surface

10. Payment term: T/T or L/C

11. Our service:

1) Sizes, materials and others are all at your requirements and can be changed.
2) Price varies on materials, dimensions, finish craft and different payment.
3) We are direct manufacture in machinery manufacturing work with experience of several decades.
4) Detail production design will be made according to information you offer.
5) We have adequate inventory, so that we can quickly delivery.
6) The most important is that we have advanced equipment.

Hot Sale Products for Hot/Cold work Mold Steel

STANDARD/GRADE Flat Bar Size(mm) Round bar Size(mm) Technics
DIN AISM JIS GB(China) Thickness Width Length Diameter Length
1.2311 P20 PDS-3 3Cr2Mo 10-460 155-2200 1600-10000 12-120 4000-6000 Forged, Hot Rolled
1.2738 P20+Ni - 3Cr2NiMnMo 21-1200 1600-2200 4000-10000 - -
1.2379 D2 SKD11 Cr12Mo1V1 6-160 155-810 3000-6000 14-80 3000-6000
1.2080 D3 SKD1 Cr12 12-90 155-610 3000-6000 10-180 3000-6000
1.2083 420 - 4Cr13 12-260 205-2000 1600-6000 12-500 3000-6000
1.2344 H13 SKD61 4Cr5MoSiV1 16-500 205-1000 3000-6000 150-450 3000-6000
1.2510 O1 SKS3 9CrWMn 9-120 155-610 3000-6000 8-80 3000-6000
1.7225 SAE4140 SCM440 42CrMo 20-280 155-2200 2000-6000 16-450 3000-10000


Warehous

DIN 1.2738 718 P20+Ni Prehardened Special Steel Flat Bar For Making Injection Mold

Processing

DIN 1.2738 718 P20+Ni Prehardened Special Steel Flat Bar For Making Injection Mold


Strict Quality Control

DIN 1.2738 718 P20+Ni Prehardened Special Steel Flat Bar For Making Injection Mold
