49inch Outdoor LCD Video Wall DID Lcd Splicing Screen 0.56mmX0.56mm 700cd/m2
49inch Outdoor LCD Video Wall DID Lcd Splicing Screen 0.56mmX0.56mm 700cd/m2
49inch Outdoor LCD Video Wall DID Lcd Splicing Screen 0.56mmX0.56mm 700cd/m2
49inch Outdoor LCD Video Wall DID Lcd Splicing Screen 0.56mmX0.56mm 700cd/m2
49inch Outdoor LCD Video Wall DID Lcd Splicing Screen 0.56mmX0.56mm 700cd/m2
49inch Outdoor LCD Video Wall DID Lcd Splicing Screen 0.56mmX0.56mm 700cd/m2
Specifications
Place of Origin :
China
Brand Name :
HUARONG
Model Number :
HE49EB
Packaging Details :
Foam - cellular carton - wooden frame - wooden case
Supply Ability :
1000 Piece/Pieces per Month
Price :
Negotiation
Type :
TFT
Application :
Indoor
Viewing Angle :
178(H)/178(V)
Pixel Pitch :
0.56mmX0.56mm
Contrast Ratio :
4000:1
Brightness :
700cd/m2
Response Time :
8ms
Input Voltage :
100/240V AC
Warranty :
1 Year
After-sales Service Provided :
Video technical support, Free spare parts, Online support
Product name :
narrow bezel LCD video wall customed
Aspect ratio :
16:9
Language switch :
Switch between Chinese and English
Operating mode :
Phones, tablets, computers, touch
Power dissipation :
200W
Certificate: :
CE/CCC/FCC/ROHS/ISO9001
Video wall Colors :
16.7M
Resolution :
1920*1080
Using occasion :
Conference room, exhibition hall, monitoring room, outdoor advertising
Way to install :
Wall hanging, floor support, cabinet, etc
Port :
port of Shenzhen
MOQ :
Negotiated
Description

49inch Outdoor LCD Video Wall DID Lcd Splicing Screen 0.56mmX0.56mm 700cd/M2

  1. Engineering Software Customized
  2. Operation Method Wire control, remote control
  3. Video Format PAL,NTSC
  4. Wide Voltage Design 100~240V AC
  5. Mounting Holes 600mm x 400mm(W x H)
  6. Installation Method Hanger (optional),Bracket (optional),Cabinet (optional)
  7. Working Humidity 10%~90%
  8. Shell Material Metal shell, anti-static, anti-magnetic field, anti-strong electric field interference
49inch super narrow bezel display for 3x3 4x4 advertising video wall


49inch series HR49E HR49EB HR49F HR49FB
Panel Type 49"DID LCD Panel(Diagonal:1232mm)
Video input CVBS(BNC) x 2, S-VIDEO(Y/C)x1
Display Color 8Bits, 16.7M
Digital input DVIx1, HDMIX1, 1080P(1920x1080)Backward Compatible
Physical Resolution 1920x1080
Pixel Pitch 0.56mmX0.56mm
Bezel gap 3.5MM 1.8MM
Power Consumption 200W 400W 200W
Dimensions 1077.6mmX607.8mm 1075.58mmX605.8mm
Single bezel Size 2.3mm,1.2mm 0.9mm
High Brightness 500cd/m2 700cd/m2 500cd/m2 700cd/m2
Screen Ratio 16:09
Response Time < 8MS
Screen Splicing Module Built-in, D-Sub15in X1, D-Sub15Out X1
HD input YPbPrX1, 1080P(1920X1080)Backward Compatible
Video Format PAL,NTSC
Operation Method Wire control, remote control
Contrast 4000:01:00
Viewing Angle 178°(H)/178°(V)
Refresh Rate 60HZ
Life(hrs) >60,000(hrs)
Computer signal input VGA x1
Installation Method Hanger (optional),Bracket (optional),Cabinet (optional)
Weight (including packaging) 13.9KG 13.5KG
Video Output CVBS(BNC)x2
Storage Temperature -20°C~60°C
Engineering Software Customized
Mounting Holes 600mm x 400mm(W x H)
Wide Voltage Design 100~240V AC
Operating Temperature 0°C~60°C
Working Humidity 10%~90%
Shell Material Metal shell, anti-static, anti-magnetic field, anti-strong electric field interference
49inch Outdoor LCD Video Wall DID Lcd Splicing Screen 0.56mmX0.56mm 700cd/m2
49inch Outdoor LCD Video Wall DID Lcd Splicing Screen 0.56mmX0.56mm 700cd/m2
49inch Outdoor LCD Video Wall DID Lcd Splicing Screen 0.56mmX0.56mm 700cd/m2
49inch Outdoor LCD Video Wall DID Lcd Splicing Screen 0.56mmX0.56mm 700cd/m2
49inch Outdoor LCD Video Wall DID Lcd Splicing Screen 0.56mmX0.56mm 700cd/m2
49inch Outdoor LCD Video Wall DID Lcd Splicing Screen 0.56mmX0.56mm 700cd/m2
49inch Outdoor LCD Video Wall DID Lcd Splicing Screen 0.56mmX0.56mm 700cd/m2
49inch Outdoor LCD Video Wall DID Lcd Splicing Screen 0.56mmX0.56mm 700cd/m2
49inch Outdoor LCD Video Wall DID Lcd Splicing Screen 0.56mmX0.56mm 700cd/m2
Company Profile
Shenzhen Huarong Electronic Technology CO., LTD.is a large-screen manufacturer integrating R & D, production, and sales. It specializes in DID LCD splicing screens, DLP rear-projection large screens, small-pitch LED displays, LCD monitors, and touch all-in-one machines. High-end display products are in a leading position in the large-screen display industry. At the same time, the HUARONG brand large screens produced have been recognized by the industry and praised by customers for their good quality. After years of rapid development, it now has self-built standard factories. Equipped with a variety of general and special production equipment, high-speed automated production lines, and Japan's imported testing and analysis instruments, while employing high-quality management personnel and R & D technicians in the industry.
The company cooperates with domestic and foreign merchants with rigorous work attitude, high-quality products and integrity, and a win-win business purpose. The company has always been adhering to the development concepts of "talent is the foundation of the enterprise" and "building a first-class enterprise, creating a first-class brand", and always keeps "quality is life". Based on market management ideas, we strive to make the [HUARONG] brand a well-known brand with international competitiveness.


FAQ
1:What is the warranty of your led display?
A:We offer 12 months warranty. and more than 100000 hours screen life span

2:what is your payment term? How long it takes to delivery?
A:We usually accept the T/T or L/C. both of them will at least 30% deposit in advance, and the rest of 70% will paid before
delivery. The lead time is usually 20 day

3:How can you ensure the led display product quality?
A:Before shipment , all the screens have aging test. and then we also have waterproof test and shake test, ensure products can transportation safety and normal use.

4:What is your pre-sale and post-sale service?
A:For pre-sale service, we have professional sales team and technical team, who are willing to answer your question within 24 hours.

For post-sale service, we will instruct you how to installation ,how to use, how to change the broken modules , and we can also send the technical to your country, in general, our led display will not have a big problem, you can rest assured to buy.
