Specifications
Place of Origin :
Shenzhen China
Brand Name :
HRD/OEM
Model Number :
PCR06,PCR10
Certification :
CE,ISO9001
MOQ :
20PCS
Price :
600usd
Packaging Details :
1PCS/1CTN,STANDARD FOR EXPORT
Delivery Time :
15-20DAYS
Payment Terms :
TT OR LC
Supply Ability :
100pcs/day
Price term :
Fob shenzhen
Warranty :
18months after shipment
Description

19 inch 4U Online High Frequency 220VAC UPS

Quick Detail:

1)Protection:Overvoltage,Low battery, overload,overheat,short circuit

2) Application: Networking,Computer room,Datacenter,server room

3)Output Voltage:220/230/240V±2%

Introduction

Power Castle Rack mount is a powerful product range with high adaptability and flexibility. Its cut-edge digital control technology of DSP (Digital Signal Processor), can greatly improve the product performance and system reliability, and deliver a compact integration with higher power density.

Perfect Application:

Network, data centre, servers and workstations, control system, communication system and office etc.

Main Features are below:

19' Rack-mount, 4U(height)

High frequency and dual conversion on-line technology

Perfect failure protection and alarm function:

Rich Communication and Monitoring Features

Advanced PFC technology

Self-diagnosis when UPS startup

Cold start feature(DC power on )

Automatically charging batteries in UPS off mode

Lightning and surge protections(surge energy rating 1050 Joules)

Fan speed automatically changes as load varies
Technical Specifications

Model

PC06R

PC06RS

PC10R

PC10RS

Capacity(linear Load)

6KVA/4800W

10KVA/8KW

Input Voltage Range

160V-286VAC

Frequency Range

45Hz~55Hz

Output Voltage

220/230/240V±2%

Output Frequency

50/60Hz±0.5Hz

Output Voltage Tolerance

<±5%(100% Load or without Load)

Distortion

<3%(Linear Load); <5%(Non-linear load)

Output Waveform

True Sine Wave

Overload Capability

105%~130%, 10Mins; >130%:1Min.

Battery Voltage

192VDC(EXTERNAL)

Charge Voltage

220VDC

Charge Current

Standard model 4A ;Long back model 8A；

Battery Type

Sealed Maintenance-FreeLead-Acid

Batteries Q'TY

16Pcs ×12VDC

Standard Backup Time(Full Load/Half Load)

5/12Mins

Crest Factor

3:1

Noise( 1m )

<45db

<50db

LCD and LED

Utility, Inverter, Bypass, Battery, Load, Battery Mode, Frequency, UPS Fault Indicator

Transfer Time of AC to DC

Zero

Battery Low Voltage

168v+/-2v

Charge Time

Charging up to 90% ,≤6Hours

Audible Alarm-Battery Discharge

Utility Failure, Beep/4s ；Battery Low, Beep/1s

EMC

50091 ,9254

UPS Abnormal

Continuous Beep and Red LED on

Output Short Circuit

Shutdown

Outlets

Terminals

Communication Interface

RS232/SNMP (optional )

Ambient Temperature

0 ℃~ 40 ℃

Humidity

10%~90%

Net Weight(Kg)

20 (L)/58 (S)

Dimension(W×D×H)mm

447*600*177

Packing Measure (W×D×H)mm

517*640*257mm
