Through-Bore Capsule Slip Ring 2 Circuits 1A

Product Description:

Features:

• Through-Bore Design: The slip ring features a through-bore design with a center aperture, allowing for easy installation and connection of other devices by passing the shaft through it.

• 2 Circuits: The slip ring has two independent Circuits, enabling simultaneous transmission of different currents or signals to meet diverse application requirements.

• 1A Rated Current: Each circuits of the slip ring has a rated current capacity of 1A, allowing for the transmission of corresponding current loads.

• High Reliability: Manufactured with high-quality materials and precision manufacturing processes, ensuring the slip ring's reliability and stability.

Typical Application:

• Pan-Tilt-Zoom (PTZ) Cameras: Capsule Slip Rings enable the continuous rotation of PTZ cameras while transmitting power and signals.

• Packaging Machinery: Capsule Slip Rings are used in packaging machines to enable the rotation of packaging heads while maintaining electrical connections.

• Robotics: Capsule Slip Rings provide power and signal transmission for various robotic applications, including robot arms and grippers.

• Wind Turbines: Capsule Slip Rings are used in wind turbines to transmit power and signals between the rotating blades and the stationary components.

Specifications:

Drawing for 3KM-T005-0201(3KM06-17-01HW):

FAQ:

What is a Capsule Slip Ring?

A Capsule Slip Ring is a device that enables the transmission of electrical signals or power between rotating and stationary parts in a rotating assembly.

How does a Capsule Slip Ring work?

A Capsule Slip Ring consists of a rotating component (rotor) and a stationary component (stator) with brushes or contacts. As the rotor rotates, the brushes or contacts maintain electrical connections with the stator, allowing the transmission of signals or power.

What are the main components of a Capsule Slip Ring?

The main components of a Capsule Slip Ring include the rotor, stator, brushes or contacts, housing, and wiring.
