Fiber Optic Slip Rings, Single-Channel Optical Signal

Product Description:

Features:

This product is a compact micro single-channel fiber optic slip ring, with an installation diameter of only 6.8mm, making it highly suitable for use in limited space installations. When the installation aperture is designed as 6.8mm, the fiber connector (10mm) will not be able to pass through, so the fiber connector may need to be processed after installation. Additionally, this product offers the option of single mode or multi-mode fiber, with excellent optical performance and water and dust resistance.

Typical application:

• Robotics: It is used in miniature robotic systems where space is limited, enabling the transmission of optical signals between the stationary base and rotating components such as miniature robotic arms or joints. This facilitates real-time data communication, control signals, and video transmission in small-scale robotic operations.

• Medical Devices: The micro single-channel fiber optic slip ring is utilized in compact medical devices, such as endoscopes or miniature surgical instruments. It allows for the transmission of high-resolution video signals, imaging data, or laser power across rotating components, enabling advanced medical procedures and imaging in tight spaces.

• Aerospace and Defense: It finds applications in miniaturized aerospace and defense systems where space and weight are critical. It enables the transmission of optical signals in compact surveillance systems, miniature drones, or microsatellites, ensuring efficient communication and data transmission.

Options:

Specifications:

Drawing for HF01A-FC001:

FAQ:

What is a micro single-channel fiber optic slip ring?

A micro single-channel fiber optic slip ring is a compact device designed to transmit optical signals between stationary and rotating components in applications with limited space.

What are the key features of the micro single-channel fiber optic slip ring?

The key features of the micro single-channel fiber optic slip ring include its small size with a mounting diameter of only 6.8mm, the ability to accommodate single-mode or multimode fibers, excellent optical performance, and its waterproof and dustproof design.

What is the application of the micro single-channel fiber optic slip ring?

The micro single-channel fiber optic slip ring finds applications in various industries, such as robotics, medical devices, aerospace, defense, industrial automation, and optical sensing systems, where space is limited, and continuous optical signal transmission is required.
