Hiscience Custom Fiber Optic Slip Rings Multi Circuits Fiber Rotary Joint
Hiscience Custom Fiber Optic Slip Rings Multi Circuits Fiber Rotary Joint
Hiscience Custom Fiber Optic Slip Rings Multi Circuits Fiber Rotary Joint
Hiscience Custom Fiber Optic Slip Rings Multi Circuits Fiber Rotary Joint
Hiscience Custom Fiber Optic Slip Rings Multi Circuits Fiber Rotary Joint
Hiscience Custom Fiber Optic Slip Rings Multi Circuits Fiber Rotary Joint
Hiscience Custom Fiber Optic Slip Rings Multi Circuits Fiber Rotary Joint
Hiscience Custom Fiber Optic Slip Rings Multi Circuits Fiber Rotary Joint
Specifications
Brand Name :
Hiscience
Model Number :
HF02I-FC001
Certification :
ISO
Place of Origin :
Shenzhen , China
MOQ :
1
Payment Terms :
T/T
Price :
Negotiate
Packaging Details :
Carton
Delivery Time :
2-6 Weeks, Stock Available
Supply Ability :
300 PCS/Week, Stock Available
Name :
Fiber Optic Slip Rings
Fiber Type :
Single Mode(9/125 μm)
NO.of Circuits :
N≤7According to customer's request
Wavelength Range :
780-1650(Default:1310& 1550 nm)
Insertion Loss :
≤ 4.0dB
Insertion Loss Variations :
≤±1.0dB
Description

Fiber Optic Slip Rings 2 to 7 Circuits of optical signals

Product Description:

Features:

Low insertion loss
Optical transmssion technology of multi- Circuit, no
electroma gnetic leakage and anti-elertromagnetic interference
leakage and anti-electromagnetic interference
Contactless signal transimission
Small size. suitable for small space

Typical application:

  • Semiconductor Manufacturing: Fiber optic slip rings are employed in semiconductor manufacturing equipment, enabling optical signal transmission in rotating stages, wafer handling systems, and inspection devices.

  • Communication Systems: Fiber optic slip rings are used in communication systems, such as undersea fiber optic cables and mobile communication towers, enabling optical signal transmission in rotating or vibrating components.

  • Food and Beverage Processing: Fiber optic slip rings find applications in food and beverage processing equipment, facilitating optical signal transmission for inspection systems, sorting machines, and packaging lines.

Options:

Number of optical Circuits
Wavelength range
Housing material
Fiber pigtail Connector type
Fiber connector typeST. LC
Installation modes

Specifications:

Technical Specifications
Fiber Type Single Mode(9/125 μm)
NO.of Circuits N≤7According to customer’s request
Wavelength Range 780-1650(Default:1310& 1550 nm)
Insertion Loss ≤ 4.0dB
Insertion Loss Variations ≤±1.0dB
Return Loss >45dB
Optical crosstalk ≥70dB
Max. Optical Power 25dBm
Roating Speed 300rmp
Working Life ≥50 million (300 rpm)
Pulling Strength ≥75N
Working Temperature -40~75℃
Storage Temperature -45~85℃
Protection(IP Grade) IP68
Housing Material Stainless Steel
Connector Type Default:FC/PC
Package Style Pigtails on both ends, default. Φ3.0mm, 1.0 meters long
Vibration Standard MIL-STD-167-1A
Mechanical shock MIL-STD-810G

Drawing for HF02I-FC001:

Hiscience Custom Fiber Optic Slip Rings Multi Circuits Fiber Rotary Joint

Hiscience Custom Fiber Optic Slip Rings Multi Circuits Fiber Rotary Joint

FAQ:

Can fiber optic slip rings transmit both data and power signals?

No, fiber optic slip rings primarily transmit optical signals. Power transmission is typically handled separately through electrical slip rings or other power transmission methods.

Are fiber optic slip rings suitable for high-bandwidth data transmission?

Yes, fiber optic slip rings are well-suited for high-bandwidth data transmission due to the inherent advantages of fiber optics, such as high data rates, low signal loss, and immunity to electromagnetic interference.

Are fiber optic slip rings susceptible to signal loss over long distances?

Fiber optic slip rings have low signal loss characteristics, which means they can transmit signals over long distances without significant degradation. However, the overall transmission distance may still be limited by the specific fiber optic cables used.
