Rotary Union with 4 circuits 10 A + 13 signals + 1 shield

Low Maintenance Requirements: Designed for durability and efficiency, this slip ring has low maintenance demands, reducing downtime and ensuring cost-effectiveness in long-term operations.

Customizable Options: The design allows for tailored configurations, such as varying bore sizes, additional circuits, or specialized connector types. These customizations cater to unique system requirements, making the slip ring compatible with non-standard industrial equipment and niche applications.

Stable Rotational Performance: The slip ring supports a rotational speed range of 0-250RPM, delivering smooth and consistent operation, ideal for rotary systems in textile machinery, rotary dryers, and material handling systems.

Typical Application:

Textile Machinery: In textile machinery, the slip ring provides stable power and signal transmission to rotating components such as rollers and cutting tools. It enhances the reliability and efficiency of operations like fabric weaving, dyeing, and finishing, ensuring consistent performance in demanding industrial environments.

Rotary Evaporators:For laboratory rotary evaporators, the slip ring ensures uninterrupted power and signal transmission to the rotating flask while supporting pneumatic vacuum operations. This combination enhances efficiency and accuracy in solvent recovery and sample preparation processes.

Agricultural Sprayers: In agricultural sprayers, the slip ring facilitates continuous power and signal transmission for spray arms, while the pneumatic channel controls air pressure for precision spraying. This ensures uniform application of fertilizers, pesticides, and herbicides, enhancing productivity.

Specifications:

Electrical Parameter Circuits/Current 8 Circuits 10A + 27 Signals + 1Shield Voltage 0-240VAC/DC Lead Wire size AWG17#22#24# Teflon Insulated RVSP-8*0.15mm² Cable Dielectric strength ≥500V@50HZ Insulation Resistance 500MΩ@500VDC Dynamic Contact Resistance ≤10mΩ Mechanical Parameter Working Speed 0-200RPM Protection(lP Grade) IP51 Working Temperature -20℃~+80°C Contact Material Precious Metal Housing Material Aluminum Alloy Pneumatic Parameter Passages 1 Passage Connection Thread Size M6, 6mm Pressure 1 Mpa Transmitting Media Compressed

Drawing:

FAQ:

Q: How long do slip rings last, and do they need maintenance?

A: Lifespan depends on usage and environment. Regular cleaning and inspections are recommended. Proper installation and operation are crucial.

Q: How do I choose the right slip ring for my application?

A: Consider signal type, current load, rotational speed, temperature range, size, and budget. Our team can provide personalized solutions and recommendations.

Q: Are your Slip Rings customizable to fit specific applications?

A: Yes! We offer custom slip ring solutions tailored to meet the unique requirements of your application. Whether it's a specific size, number of circuits, or operating conditions, our engineering team can design a product that perfectly fits your needs.

Electrical Parameter Circuits/Current 8 Circuits 10A + 27 Signals + 1Shield Voltage 0-240VAC/DC Lead Wire size AWG17#22#24# Teflon Insulated RVSP-8*0.15mm² Cable Dielectric strength ≥500V@50HZ Insulation Resistance 500MΩ@500VDC Dynamic Contact Resistance ≤10mΩ Mechanical Parameter Working Speed 0-200RPM Protection(lP Grade) IP51 Working Temperature -20℃~+80°C Contact Material Precious Metal Housing Material Aluminum Alloy Pneumatic Parameter Passages 1 Passage Connection Thread Size M6, 6mm Pressure 1 Mpa Transmitting Media Compressed AirElectrical Parameter Circuits/Current 8 Circuits 10A + 27 Signals + 1Shield Voltage 0-240VAC/DC Lead Wire size AWG17#22#24# Teflon Insulated RVSP-8*0.15mm² Cable Dielectric strength ≥500V@50HZ Insulation Resistance 500MΩ@500VDC Dynamic Contact Resistance ≤10mΩ Mechanical Parameter Working Speed 0-200RPM Protection(lP Grade) IP51 Working Temperature -20℃~+80°C Contact Material Precious Metal Housing Material Aluminum Alloy Pneumatic Parameter Passages 1 Passage Connection Thread Size M6, 6mm Pressure 1 Mpa Transmitting Media Compressed Air
