DIN 5157 HSS M2 Hand Pipe Tap , White Finished Manual Pipe Thread Tap Set
DIN 5157 HSS M2 Hand Pipe Tap , White Finished Manual Pipe Thread Tap Set
DIN 5157 HSS M2 Hand Pipe Tap , White Finished Manual Pipe Thread Tap Set
DIN 5157 HSS M2 Hand Pipe Tap , White Finished Manual Pipe Thread Tap Set
DIN 5157 HSS M2 Hand Pipe Tap , White Finished Manual Pipe Thread Tap Set
DIN 5157 HSS M2 Hand Pipe Tap , White Finished Manual Pipe Thread Tap Set
Specifications
Brand Name :
STARRY
Model Number :
G1/8-G4
Certification :
ISO9000
Place of Origin :
CHINA
MOQ :
100 sets
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
15000pcs per day
Delivery Time :
35days
Packaging Details :
plastic box
Material :
HSS-4341;HSS-M2;HSS-M35
Surface :
Fully Ground
Standard :
DIN5157
Precision :
H1 H2 H3 H4
Application :
Manual Tapping , Thread Tapping
Description

DIN 5157 HSS M2 Hand PipeTap , White Finished Manual Pipe Thread Tap Set

Description of hss machine taps :

1. Complete hole drilling, tapping, deburring and countersinking in one operation with power drill saves labor and time.
2. Self-centering point, do not need assistant center drilling or center punching.
3. Taps produce internal threads in previously formed holes and can be used in machines (such as drill presses) or with
hand tools.
4. Modified bottoming chamfer has additional length to reduce chip load, add tool life, and permit higher tapping speeds.
5. High-speed steel tools are good for most general purpose applications, offering a combination of hardness and
toughness for wear resistance.
6. Made from HSS with titanium coated, high hardness and rust resistance, durable and long service life.
7. Suitable for drilling, tapping, cutting on soft metal, aluminum plate, iron, etc.

Specification

DIN5157,for metric-ISO thread DIN13,Tolerance 6H=is02
M2 HSS
M35 HSS -E,Coatings,avaliable for specified requirements
2 of set:Taper and Plug.
For through holes and blind holes.

Product Name DIN5157 G hand taps sets
Material: HSS-4241;HSS-4341;HSS-M2;HSS-M35
Surface: white finished.
Application suitable for alloyed and unalloyed steel up to approx. 850 N/mm², cast steels, malleable cast iron, brass, aluminium and copper



size

SIZE OVERALL LENGTH THREAD LENGTH
G1/8 63 20
G1/4 70 22
G3/8 70 22
G1/2 80 22
G5/8 80 22
G3/4 90 22
G7/8 90 22
G1 100 25
G1-1/8 125 40
G1-1/4 125 40
G1-3/8 140 40
G1-1/2 140 40
G1-5/8 140 40
G1-3/4 140 40
G2 160 40
G2-1/4 160 40
G2-1/2 160 40
G2-3/4 160 40
G3 160 40
G3-1/2 180 45
G4 180 45


Application of hss machine taps :

Used for tapping through and blind holes. Recommended for threading in mould steels, unalloyed and low alloyed steels, cast

, NE- metals, zinc, magnesium alloys, and thermoplastic metals.

pic show

DIN 5157 HSS M2 Hand Pipe Tap , White Finished Manual Pipe Thread Tap Set
DIN 5157 HSS M2 Hand Pipe Tap , White Finished Manual Pipe Thread Tap Set
