china acid resistant refractory brick/block with attractive price
china acid resistant refractory brick/block with attractive price is a kind of insulation material adopting organic matter as ignition loss substance in order to increase the porosity of refractory, which has such advantages as high porosity, small volume density, good insulation effect, high mechanical intensity, small thermal conductivity and long service life. For various industrial kilns & furnaces, it is a kind of essential refractory for energy saving and temperature preservation.
It is a kind of the light weight refractory products which contains the alumina content range from 20% to 48% .
Feature of china acid resistant refractory brick/block with attractive price:
High refractoriness,High-temperature endurable .
Good corrosion resistance.
Good spalling resistance and wear resistance.
Good thermal shock resistance.
High mechanical strength.
High-temperature creep rate is low.
Good volume stability at high temperature.
Production Process of china acid resistant refractory brick/block with attractive price brick:Crushing→Mixing→Shaping→Drying→Firing→Inspection→Packaging and Shipment
china acid resistant refractory brick/block with attractive price
Physical and Chemical Indexes of china acid resistant refractory brick/block with attractive price
Sunrise Brand | HT-0.5 | HT-0. 6 | HT-0. 8 | HT-1.0 | HT-1.3 |
USA Brand | ISO125-0.5 | ISO125-0.6 | ISO135-0.8 | ISO135-1.0 | ISO140-1.2 |
Max Service Temperature (°C) | 1150 | 1200 | 1280 | 1300 | 1350 |
Bulk Density (g/cm3) | 0.55 | 0.6 | 0.8 | 1.0 | 1.3 |
Apparent Porosity % | 80 | 70 | 60 | 55 | 50 |
Cold Crushing Strength (Mpa) ≥ | 1.5 | 2.0 | 2.5 | 3.0 | 4.0 |
Reheating Linear Change (%) °CX 12H ≤ | 1250°C -0.5 | 1300°C -0.5 | 1350°C -0.5 | 1350°C -0.9 | 1350°C -0.9 |
Thermal conductivity(W/m.k) | 400°C | 0.14 | 0.25 | 0.35 | 0.41 |
600°C | 0.16 | 0.29 | 0.45 | 0.43 |
What is the Shapes &Sizes of our china acid resistant refractory brick/block with attractive price?
Straight | Split | Arch | Wedge | Tile | Other Shape |
L×W×H(mm) 230×114×65 230×114×75 | L×W×H (mm) 230×114×25 230×114×32 230×114×37 230×114×50 | L×W×H/h(mm) 230×114×65/45 230×114×65/55 230×114×75/45 230×114×75/55 230×114×75/65 | L×W×H/h (mm) 230×114×65/45 230×114×65/55 220×114×75/45 220×114×75/55 220×114×75/65 | L×W×H (mm) 230×230×38 230×230×50 230×230×65 230×230×75 | Key brick, Skew brick, Soap, Checker, Neck, Taper, |
We also can make insulation brick according to customers' drawing and requirements. |
china acid resistant refractory brick/block with attractive price
Applications of china acid resistant refractory brick/block with attractive price
1.widely in insulating layers of various thermal equipments
2.bast furnace, hot blast furnace, coke oven
3.Chimney lining.
china acid resistant refractory brick/block with attractive price
Shipping of china acid resistant refractory brick/block with attractive price
1. FEDEX/DHL/UPS/TNT for samples.
2. By Sea for batch goods.
3. Customers specifying freight forwarders or negotiable shipping methods.
4. Delivery Time:3 days for common shape samples;15 days for special.
5.shape samples.Within 30 days for batch goods.
Henan hongtai kiln refractory co., LTD. is establised in 2012,located in Xinmi City, 40 kilometers southwest of Zhengzhou City in Henan Province, close to JingGuang,Longhai railway lines, with road transport facilities.Rich resoures of Refractory materials, adequate and qualified fuel in this area, provide unique conditions for refractory production,shipping and refractory industry development.
Henan hongtai kiln refractory co., LTD. has been always adhere to the principle of "quality first, credibility first, users first, quanlity and efficiency", has won the honor of "national measurement of qualified units""service standardization standards unit",which are recognized by higher office, was rated as Henan Province Contract and Keeping Promises Company, and has passed through ISO 9001:2000 Quality Mnagement System Confirmatrion, In order to meet the needs of market developemtn, we establish a "production, learning,research"strategic partnership with High Temperature Research Institute of Henann University of Science and Tchnology,and maintain long-term technical cooperation with Luoyang refractory research Institutions, the Iron and Steel Desigh Institute, Wuhan Iron and Steel Design Istitute and other scientific research institutions.Constantly adjust the production process,update product quality,built a solid foundation for wining a higher market hornor. Besides,all staff of high and low temperature furnace desigh, installation, manufacture, commissioning capacity of the company commit to every client: According to the different needs of users, we will thank all users' care by better service,higher product quality!
Production Equipments:
Test Equipments:
Packing:
Standard export wooden pallet with cardboard and PET strap.
1. Strong packing will protect the goods from any possible damage during transit.
2. Solid packing and overall stuffing can prevent the cases from vibration and jarring.
3. We must take necessary precaution that the packing can protect goods from pilferage or rain.
4. We can confirm that we take every possible precaution to ensure that our products reach our customers all over the world in prime conditon.
Shipping:
By vessel or by train from any Chinese port, Samples can be delivered by International express.
Delivery:
15-30 days working day for large quantity. The shipment we will arrange as soon as possible. Of course, if it is a custom products, the shipping time will delay.
Sample:
Usually by EMS, DHL, UPS, TNT, FedEx. Anyway you like. Bulk order: Usually by sea.
Payment:
It can be through T/T, L/C at sight. The specific terms determined according to the quantity of the goods, etc.
Your inquiry related to our product & price will be replied within 24 hours.
Export:
Our products have been exported to many countries: Australia, Chile, USA, Russia, UK, Indonesia, etc., good quality have be approved by our clients.
Q1: How about your factory’s annual production capacity?
A1:HongTai annual production is about 310,00Tons.
Q2: How many production lines of your factory?
A2:HongTai has 6 production lines, including eight silicon bricks lines, and each one of mullite brick, high alumina brick, insulating brick and monolithics line.
Q3:How large the scale of your factory?
A3: HongTai covers almost 200,000 Square meters, including plant area of 180,000 square meters.
Q4: What’s your factory’s product scope?
A4:HongTai main products are: refractory for hot blast stove, refractory for coke oven, refractory for glass kiln, refractory for carbon calcining furnace.
