4x8ft Exterior Aluminium Wall Panels , ASTM 6mm ACM Panels In Exhibition
4x8ft Exterior Aluminium Wall Panels , ASTM 6mm ACM Panels In Exhibition
4x8ft Exterior Aluminium Wall Panels , ASTM 6mm ACM Panels In Exhibition
4x8ft Exterior Aluminium Wall Panels , ASTM 6mm ACM Panels In Exhibition
4x8ft Exterior Aluminium Wall Panels , ASTM 6mm ACM Panels In Exhibition
4x8ft Exterior Aluminium Wall Panels , ASTM 6mm ACM Panels In Exhibition
4x8ft Exterior Aluminium Wall Panels , ASTM 6mm ACM Panels In Exhibition
4x8ft Exterior Aluminium Wall Panels , ASTM 6mm ACM Panels In Exhibition
4x8ft Exterior Aluminium Wall Panels , ASTM 6mm ACM Panels In Exhibition
4x8ft Exterior Aluminium Wall Panels , ASTM 6mm ACM Panels In Exhibition
4x8ft Exterior Aluminium Wall Panels , ASTM 6mm ACM Panels In Exhibition
4x8ft Exterior Aluminium Wall Panels , ASTM 6mm ACM Panels In Exhibition
Specifications
Brand Name :
Huabond
Model Number :
H-A506
Certification :
ASTM, ISO, CE & SGS
Place of Origin :
Changsha, China
MOQ :
600 sqm
Payment Terms :
T/T, L/C
Delivery Time :
18-22 days
Packaging Details :
wooden pallet
Description

Aluminium Composite wall Panel Exterior

Quick Details

Size: 1220mm*2440mm

Place of Origin: Shanghai, China

Brand Name: HUABOND

Model Number: H-A506

Usage: Outdoor, Interior / Exterior

Application: Decoration

Standard size: 1220*2440mm

Gross weight per batch: 5000.0 kg

Package size per batch: 122X244X12 cm

Panel thickness: 2mm/3mm/4mm/5mm/6mm

Aluminum sheet thickness: 0.15mm,0.21mm,0.30mm,0.40mm,0.50mm

Core: Recycle PE Core/Fireproof PE Core/Unbreakable PE Core

Surface Treatment: Anodized, Brushed, Foil Decoration, Mirror, PE Coated, Printing, PVDF Coated

Product name: Wall cladding 4mm commercial Exterior PVDF Aluminum Composite Panel

Coating: PE/PVDF/NANO/Anti-scratch

Color: Solid / Wood / Brushed / High gloss / Mirror / Marble

Certificate: ISO9001 ISO14001 OHSAS18001

4x8ft Exterior Aluminium Wall Panels , ASTM 6mm ACM Panels In Exhibition

Product name Huabond
Aluminum skin thickness 0.1mm-0.50mm
Total panel thickness 2mm-6mm
Width 1220mm(regular),1250mm,1300mm,1500mm,1550mm, 1575mm,2000mm(maximum)
Length Up to 8000mm
Standard size 1220mm(Width) ×2440mm(Length)
Available Color all colors on all professional color cards.
Core material Unbroken(good) and broken core(normal)
Surface Treatment PVDF coating
Application 1) Constructional exterior curtain walls, Wall Panel are widely used in exhibition, stores, offices, banks, hotels, restaurants and apartments;
2) Decorative renovation for storey-added old buildings, facades, roofing;
3) Indoors decoration for interior walls, ceilings, bathrooms, kitchens, balconies and subway;
4) Advertisement board, display platforms, billboards and signboards;
5) Wallboard and ceilings for tunnels;
6) Raw materials in industrial purpose;
7) Material used for vehicle bodies, yachts and boat

4x8ft Exterior Aluminium Wall Panels , ASTM 6mm ACM Panels In Exhibition

More Details

Payment term TT, LC at sight
Lead time 18-22 days
Quality Control ISO9001:2000
Quality standard GB/T17748-2008
Production Capability 300000 SQM/Month
More service OEM, Free samples, Free color chart make, 15-20days fast delivery, high quality

Panel Width 1220mm,1250mm,1500mm,1550mm,2000mm(maximum)
Panel Length up to 6000mm
Standard Size 1220×2440mm,Customized Accepted
Panel Thickness 2mm,3mm,4mm,5mm,6mm
Aluminum Thickness 0.05mm to 0.50mm
Aluminum Alloy AA1100, AA3003, AA5005 ...
Coating PE Coating, PVDF Coating, NANO
PE Core Recycle PE Core, Fireproof PE Core, Unbreakable PE Core
Color Metallic, Solid, Glossy, Pearl, Brushed, Mirror, Granite, Wooden
Delivery Time Within 14 days after receiving deposit
MOQ 500 SQM
Payment Terms T/T,L/C,PAYPAL
More Services OEM, Free Samples, Color Matching

Product Description

1) Front side: aluminum alloy sheet coated with fluorocarbon resin(PVDF) or polyester resin (PE) roasting painting
2) Core material: nontoxic polyethylene, PE, FR, LDPE
3) Back side: aluminum alloy sheet coated with polyester resin painting(PE)

4x8ft Exterior Aluminium Wall Panels , ASTM 6mm ACM Panels In Exhibition

Features

Torsion Strength

High resistance to pressure and force exertion; High flexibility; No damages to paint layer when curved; Resistant to corrosion even by sand storm;

Easy Processing & Installation

Easy to process due to its light weight; Superior constructibility make it easy to cut, plan edge, bend and form with simple tools;

Thermal Resistance

HUABOND ACP’s have insulating properties that prevent heat to penetrate structures, which translates into energy savings;

Fire Resistance

PE plastic core plate is adopted as the flame retarding substance in between difficult-combustible aluminum layers; Fireproof ability is higher than B1 grade standard;

Weather Resistance

PVDF coating(KYNAR-500)material provides good weatherability. The surface will not be damaged under any climate; Color will last longer;

Even Coat &Various Colors

HUABOND ACP’s use advanced film technology, making the joining of paint and panel strong and uniform; Diversity of colors can satisfy your different requirements;

High Impact Resistance

Innovative composite production of viscoelastic core fused with durable aluminum membranes provides high impact and breakage resistance; HUABOND ACP is strong and rigid;

Peel Strength

Advanced technology is applied in HUABONDACP’s which enhances the key factor, peel strength, to an excellent condition; Planeness of panel has been largely improved;

Sound Resistance

The unique non-combustible polyethylene core of HUABOND ACP’s provides sound reducing properties better than other materials such as wood and steel;

Easy to Maintain

HUABOND ACP’s enjoy the advantage of self-cleaning; Neutral detergent and water are enough to keep it clean

4x8ft Exterior Aluminium Wall Panels , ASTM 6mm ACM Panels In Exhibition

SPECIFICATIONS:

Normal Width 1220mm , 1250mm, 1500mm, 1570mm ...
Panel Thickness 2mm , 3mm, 4mm, 5mm, 6mm
Aluminum Alloy AA1100, AA3003, AA5005
Aluminum Thickness 0.08 mm - 0.50 mm
Coating PE/PVDF/NANO/Anti-scratch/Mill
PE Core Recycle / Fireproof / Unbreakable PE Core
Color Solid; Metallic; Marble; Wood; Brush; Glossy and other colors
Pencil hardness 2H
Toughness of coating 2T
Elongation 5 %
Tensile strength 130 Mpa
Temp Resistance -50°C to +90°C

4x8ft Exterior Aluminium Wall Panels , ASTM 6mm ACM Panels In Exhibition

Application

1. Exterior Application

Wall Cladding, Facades, Roofs and Canopies, Tunnels, Column covers or Renovations

2. Interior Application

Wall Cladding, Ceiling, Bathrooms, Kitchens and Balconies

3. Advertisement and Market Application

Display platforms, Signboards, Fascia and Shop fronts etc.

Advantages:

1, Fast delivery

2. Competitive price

3. Many years trading experience

4. Many years exhibition experience

5. Professional designer group service

6. Offer one-stop solution project service

7. Cooperation with famous brand enterprise

8. Offer certification, quality guaranteed

9. Provide personalized custom service.

4x8ft Exterior Aluminium Wall Panels , ASTM 6mm ACM Panels In Exhibition
