140°C Industrial Microwave Dryer HY-DY600 For Microwave Drying And Moisture Analysis
140°C Industrial Microwave Dryer HY-DY600 For Microwave Drying And Moisture Analysis
Specifications
Brand Name :
Huaemw
Model Number :
DY600
Place of Origin :
China
MOQ :
1 PCS
Price :
Negotiable
Delivery Time :
1~12weeks
name :
Microwave Reactor
Heating Source :
Microwave & Electric
Working Temperature :
140°C
Microwave Leakage Prevention :
<2mW/cm2
Temperature Measurement Method :
Thermocouple
warranty :
1 year
Description

140°C Industrial Microwave Dryer HY-DY600 For Microwave Drying And Moisture Analysis

  • Description

HY-DY600 is industrial dryer with multiple heating source ie. microwave and electric, which can heat materials with high efficiency, thus drying time can be reduced from hours to minutes.

HY-DY600 is equiped with a weighing system to feed back real-time weighing resuilts which is benefit for subsequent analysis.

HY-DY600 features an auto rotary loading tray to ensure even heating uniformity

  • Applications

The industrial heating and drying oven HY-DY600 is designed for removing moisture from samples, thus is suitable for rapid drying and moisture analysis.

  • Technical Parameters
Parameters HY-DY600
Power Voltage 380V±10V 50Hz
Rated Power 10KW
Electrical Heating Power 4kW
Microwave
System		 Microwave
Output Power		 0.10~5.60KW
continuously adjustable
Microwave Frequency 2.45GHz
Microwave Leakage Prevention microwave leakage intensity<2mW/cm2
Thermal
Insulation System		 Temperature 140°C
Heating Space(L×W×H) 450×490×290mm
Temperature Control
System		 Temperature
Measurement Method		 thermocouple
Temperature
Measurement Range		 0~800°C
Temperature
Control Precision		 ±0.1%
Control
System		 Auto, Manual and Isothermal Controlling Mode,
PLC+Touch Screen		 40 segments of programmable technical parameters,
data storage and export,
real-time curve data display,
dynamic data display
Weighing System deflection angle weighing sensor configurated with self-developed transition device
Exhaust Sysytem centrifugal fan CY112-H
Loading Sysytem auto rotary loading tray
Safety
System		 Magnetron Alarm over temperature alarm
Furnace Door Protection Alarm furnace door shutdown sensor
Cooling
System		 High Precision
Cooling-Water Machine		 flow rate of 2m3/h,
rated cooling capacity of 3.6KW
Overall
Dimension		 Furnace Body(L×W×H) ca. 2100×1600×2000mm
