HY-TRJ1510E White Lab Continuous Pyrolysis Furnace 40mm Tube Waste Salt Pyrolyzing
HY-TRJ1510E White Lab Continuous Pyrolysis Furnace 40mm Tube Waste Salt Pyrolyzing
HY-TRJ1510E White Lab Continuous Pyrolysis Furnace 40mm Tube Waste Salt Pyrolyzing
HY-TRJ1510E White Lab Continuous Pyrolysis Furnace 40mm Tube Waste Salt Pyrolyzing
Specifications
Brand Name :
Huaemw
Model Number :
HY-TRJ1510
Place of Origin :
China
MOQ :
1 PCS
Price :
Negotiable
Delivery Time :
1~12weeks
Heating Source :
Microwave & Electric
Working Temperature :
1050°C
Temperature Control Precision :
±0.1%
Temperature Measurement Method :
thermocouple
Heating Space (D×L) :
Φ40×150mm
warranty :
1 year
Description

HY-TRJ1510E White Lab Continuous Pyrolysis Furnace 40mm Tube Waste Salt Pyrolyzing

  • Product Features​

Pyrolysis is the thermal decomposition process of materials at high temperature with an inert atmosphere. Pyrolysis furnace enables removal of solid and liquid organic contaminants from wastes.

Traditional resistance wire heated pyrolyzer is of poor temperature accuracy and reproducibility because of non-uniform heating.

For many materials, the product of pyrolytic decomposition can be recycled as a source of carbon for a downstream process.

HY-TRJ1510E is lab used continuous prolysis furnace with a working tube 40mm in diameter.

  • Applications

HY-TRJ1510E allows to heat organic material in absence of oxygen for a wide range of industrial applications like energy or chemicals production, thus is suitble for pyrolyzing materials such as organic waste salt, activated carbon, biomass, coal, rubbish and plastics etc. with high efficiency and continuity.

HY-TRJ1510E is specially suitable for pyrolyzing waste salt with high efficiency in an environment friendly way.

  • Technical Parameters
Parameters HY-TRJ1510E
Power Voltage 380V±10V 50Hz
Rated Power 5KW
Electrical Heating Power 2KW
Microwave System Microwave Output Power 0.10~1.40KW continuously adjustable
Microwave Frequency 2.45GHz
Microwave Leakage Prevention microwave leakage intensity <2mW/cm2
Thermal Insulation System Tmax 1100°C
Working Temperature 0~1050°C
Heating Space (D×L) Φ40×150mm
Temperature Control System Temperature Measurement Method thermocouple
Temperature Measurement Range 0~1300°C
Temperature Control Precision ±0.1%
Control System Auto, Manual and Isothermal Controlling Mode,
PLC+Touch Screen		 40 segments of programmable technical parameters, data storage and export, real-time curve data display, dynamic data display
Safety System Magnetron Alarm over temperature alarm
Overall Dimension Furnace Body(L×W×H) ca. 580×790×1150mm
