Rotary Working Vacuum Tube Furnace Monitoring Window Temperature Ajustable
Rotary Working Vacuum Tube Furnace Monitoring Window Temperature Ajustable
Specifications
Brand Name :
Huaemw
Model Number :
HY-LZG3016
Place of Origin :
China
MOQ :
1 PCS
Price :
Negotiable
Delivery Time :
1~12weeks
Heating Elements :
Microwave Absorbing SiC
Voltage :
380V±10V
Working Temperature :
0~1550℃
Classification :
Laboratory Heating Equipments
Usage :
Thermal Treatment Furnance
warranty :
1 year
Description

Microwave Machine, Rotary Working Tube, Monitoring Window, Temperature Ajustable

  • Product Features

HY-LZG3016 features rotary working tube to ensure sample material to be heated in more even temperature field.

HY-LZG3016 uses PLC control system to ensure Auto, Manual and Isothermal 3 Controlling Modes.

HY-LZG3016 has monitoring window to ensure real time display or monitoring of the heating process.

Max. 1600°C HY-LZG3016 tube furnace offers energy efficient design with an economical price.

  • Applications

HY-LZG3016 is suitable for a range of applications that require processing flexibility with fast heatup and recovery rates.

  • Technical Parameters
ParametersHY-LZG3016
PowerVoltage380V±10V 50Hz
Rated Power6KW
Microwave
System		Microwave Output Power0.10~2.80KW
continuously adjustable
Microwave Frequency2.45GHz
Microwave Leakage Preventionmicrowave leakage intensity <2mW/cm2
Thermal
Insulation System		Tmax1600°C
Working Temperature0~1550°C
Heating Space
(diameter×width)		Φ60×120mm
Temperature Control
System		Temperature
Measurement Method		infrared thermometer
Temperature
Measurement Range		300~1800°C
Temperature
Control Precision		±0.1%
Control
System		Auto, Manual and Isothermal Controlling Mode,
PLC+Touch Screen		40 segments of programmable technical parameters,
data storage and export,
real-time curve data display, dynamic data display
Atmosphere SystemStatic Ultimate
Vacuum Degree		≤100Pa
Atmosphere Rangequick pre-vacuum pumping,
capalble of oxidizing gas, inert gas, weak reducing gas etc.
Safety SystemMagnetron Alarmover temperature alarm
Furnace Door Protection Alarmfurnace door shutdown sensor
Overall
Dimension		Furnace Body(L×W×H)ca. 800×600×1000mm
