Scientific Research High Temperature Tube Furnace Powder Or Small Size Sample Heating
Scientific Research High Temperature Tube Furnace Powder Or Small Size Sample Heating
Specifications
Brand Name :
Huaemw
Model Number :
HY-ZG3016
Place of Origin :
China
MOQ :
1 PCS
Price :
Negotiable
Delivery Time :
1~12weeks
name :
Microwave Tube Furnace
Working Temperature :
0~1550℃
Chamber Size :
530×430×380mm (L×W×H)
Microwave Output Power :
0.10~2.80KW continuously adjustable
Temperature Measurement Method :
Infrared Thermometer
Static Ultimate Vacuum Degree :
≤100Pa
Description

Tube Sintering Furnace, Scientific Research, Powder Or Small Size Sample Heating

  • Product Features

Tube Sintering Furnace HY-ZG3016 provides fast heating and homogenous heat distribution, which is achieved by using microwave-absorbing heating conductors silicon carbide.

HY-ZG3016 uses corundum tube or alundum tube as working tube, which ensures the machine to work continuously under 1600 degrees.

HY-ZG3016 tube furnace adopts a vertical position and can be customized to horizontal position.

  • Applications

HY-ZG3016 tube furnace is an ideal choice for sintering all types of materials especially small size samples and is great for scientific research or industrial use.

  • Technical Parameters
Parameters HY-ZG3016
Power Voltage 380V ± 10V 50Hz
Rated Power 5KW
Microwave
System		 Microwave
Output Power		 0.10~2.80KW
continuously adjustable
Microwave Frequency 2.45GHz
Microwave Leakage Prevention microwave leakage intensity <2mW/cm2
Thermal
Insulation System		 Tmax 1600°C
Working Temperature 0~1550°C
Heating Space
(diameter×width)		 Φ60×120mm
Temperature Control
System		 Temperature
Measurement Method		 infrared thermometer
Temperature
Measurement Range		 300~1800°C
Temperature
Control Precision		 ±0.1%
Control
System		 Auto, Manual and Isothermal Controlling Mode,
PLC+Touch Screen		 40 segments of programmable technical parameters,
data storage and export,
real-time curve data display, dynamic data display
Atmosphere System Static Ultimate
Vacuum Degree		 ≤100Pa
Atmosphere Range quick pre-vacuum pumping,
capalble of oxidizing gas, inert gas, weak reducing gas etc.
Safety System Magnetron Alarm over temperature alarm
Furnace Door Protection Alarm furnace door shutdown sensor
Overall
Dimension		 Furnace Body(L×W×H) ca. 530×430×380mm
Rack(L×W×H) ca. 900×500×700mm
