Sanitary Aisi 304 Stainless Steel Tank Bottom Ball Valve 10 Bar
Sanitary Aisi 304 Stainless Steel Tank Bottom Ball Valve 10 Bar
Sanitary Aisi 304 Stainless Steel Tank Bottom Ball Valve 10 Bar
Sanitary Aisi 304 Stainless Steel Tank Bottom Ball Valve 10 Bar
Specifications
Brand Name :
Huatao
Model Number :
HT-Butterfly Valve
Certification :
ISO
Place of Origin :
China
MOQ :
1 piece
Price :
USD 400 per piece
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
500 PCS Per Month
Delivery Time :
10-15days
Packaging Details :
Wooden case
Product name :
Ball Valve
Industries :
Dairy, Food, Beverage, Pharmacy, Cosmetic, Chemical
Media :
Water
Body material :
AISI-304,316L
Temperature range (PTFE) :
-20~ 350°F
Max.working pressure(PTFE) :
10 bar (147psi)
Description

Sanitary Stainless Steel Tank Bottom Ball Valve

Sanitary Ball Valve Introduction:

The stainless steel sanitary ball valve is made of SUS304 and 316L, which can meet the special requirements of various media in the food and biopharmaceutical fields. Its smooth, seamless, and automatic emptying handicraft fluid channels are also very suitable for cleaning in place when steam is stepped on it. In the process of manufacturing and processing, the quality control is strictly carried out according to the requirements of the FDA, and the computer three-dimensional design is adopted, which is manufactured for the requirements of GMP.

It can meet the special requirements of various media in the fields of food and biopharmaceuticals. Its smooth, seamless, and automatic emptying manual process fluid channels are also very suitable for the needs of steam and other CIP cleaning in place.

Feature:

1. All-copper gear design,high accuracy output torque,especially for multi-channel scaling system.
2.Small size,compact structure.
3.A variety of control methods,either to accept remote valve position control signal,but also the feedback signal in place for computer intelligence unit testion.
4.Good sealing performance

Working Principle:

1. In the closed position, the ball is pressed against the valve seat by the mechanical pressure of the valve stem.

2. When the hand wheel is turned counterclockwise, the valve stem moves in the opposite direction, and the angular plane at the bottom makes the ball disengage from the valve seat.
3. The valve stem continues to lift and interacts with the guide pin in the helical groove of the valve stem, causing the ball to start rotating without friction.
4. Until it reaches the fully open position, the valve stem is raised to the limit position, and the ball rotates to the fully open position.

Parameters

Model No.
Sanitary Penumatic Tank Bottom Valve
Size
1-4"
Working Pressure
Medium Pressure
Material
Body: SUS304, SUS316L etc.
Gasket: EPDM, PTFE, etc.
Standard
ISO, DIN, IDF, 3A, SMS etc.
Working Temperature
Normal Temperature
Connection
Welding, Thread, Clamped(Quick-Install), Flange etc.
Application
Dairy, Food, Drink, Beer, Cosmetics, Fine Chemical etc.
Drive
Manual, Pneumatic, Electric etc.
Surface Treatment
Mirror Polish, Matte etc.
Machine Processing
The Most Advanced CNC Machine From Japan For Processing.
Certificate
CE, 3A, IAF, ISO9001 etc.
