02310CRM,OSXD22N00,Optical Module - SFP+-10G-Multimode Module (1310nm, 0.22km, LC, LRM)
02310CRM,OSXD22N00,Optical Module - SFP+-10G-Multimode Module (1310nm, 0.22km, LC, LRM)
02310CRM,OSXD22N00,Optical Module - SFP+-10G-Multimode Module (1310nm, 0.22km, LC, LRM)
02310CRM,OSXD22N00,Optical Module - SFP+-10G-Multimode Module (1310nm, 0.22km, LC, LRM)
02310CRM,OSXD22N00,Optical Module - SFP+-10G-Multimode Module (1310nm, 0.22km, LC, LRM)
02310CRM,OSXD22N00,Optical Module - SFP+-10G-Multimode Module (1310nm, 0.22km, LC, LRM)
02310CRM,OSXD22N00,Optical Module - SFP+-10G-Multimode Module (1310nm, 0.22km, LC, LRM)
02310CRM,OSXD22N00,Optical Module - SFP+-10G-Multimode Module (1310nm, 0.22km, LC, LRM)
02310CRM,OSXD22N00,Optical Module - SFP+-10G-Multimode Module (1310nm, 0.22km, LC, LRM)
02310CRM,OSXD22N00,Optical Module - SFP+-10G-Multimode Module (1310nm, 0.22km, LC, LRM)
02310CRM,OSXD22N00,Optical Module - SFP+-10G-Multimode Module (1310nm, 0.22km, LC, LRM)
02310CRM,OSXD22N00,Optical Module - SFP+-10G-Multimode Module (1310nm, 0.22km, LC, LRM)
Specifications
Model Number :
OSXD22N00
Place of Origin :
China
Product name :
OSXD22N00
Supply Ability :
200 Piece/Pieces per Week
Price :
Negotiable
Brand Name :
Huawei
Certification :
CE FCC RoHS
MOQ :
Negotiable
Packaging Details :
Export carton package
Delivery Time :
7-15 days
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Description
UONEL CO LIMITED

Contact person:Natasha

Mobile/Whatsapp/Skype/Wechat:+86 13798264392

Website:www.uonel.com
www.uonel-telecom.com

S7700 Network Switches 10GE SFP+ Modules OSXD22N00

Specifications

Item

Description

Part Number

02310CRM

Version Support

Supported in V100R001C00 and later versions

Transceiver form factor

SFP+

Transmission speed

10GE

Center wavelength (nm)

1310

Standard compliance

10GBASE-LRM

Connector type

LC

Applicable cable and maximum transmission distance

  • Multimode fiber (with diameter of 62.5 μm): 220m

  • Multimode fiber (OM1) (with diameter of 62.5 μm): 220m

  • Multimode fiber (with diameter of 50 μm): 100m

  • Multimode fiber (OM2) (with diameter of 50 μm): 220m

  • Multimode fiber (OM3) (with diameter of 50 μm): 220m

Modal Bandwidth

  • Multimode fiber: 160/500 MHz*km

  • Multimode fiber (OM1): 200/500 MHz*km

  • Multimode fiber: 400/400 MHz*km

  • Multimode fiber (OM2): 500/500 MHz*km

  • Multimode fiber (OM3): 1500/500 MHz*km

Transmit power (dBm)

-6.5 to +0.5

Maximum receiver sensitivity (dBm)

-6.5

Overload power (dBm)

1.5

Extinction ratio (dB)

≥ 3.5

Operating temperature

0°C to 70°C

Packaging & Shipping

02310CRM,OSXD22N00,Optical Module - SFP+-10G-Multimode Module (1310nm, 0.22km, LC, LRM)

Our Services

100% Low Price Guarantee:
Uonel provides high-quality products at low wholesale prices
100% Quality Assurance:
All items are ORIGINAL NEW and GENUINE only.
Free Technical Support:

Our FREE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.

100% Money Back Guarantee:
You can contact our customer service team to exchange or return any product that you bought from us.

Flexible Secure Payment & Shipment:
Verified authorization: Mcafee Secure, VeriSign Secured

Company Information

Uonel is one of the biggest Cisco& Network Hardware distributor in china, founded in 2008. We are a global provider of netwotking products with more than 5000 customers.

We provide original new &Cisco Routers,Switches,Firewalls,Wireless APs & controllers,OLTs,GPON modems,optical transceivers.Our company have more than $5million &Cisco products in stock.

Most of our technical engineers had work exprience in company,we can provide network design&planning,configration,troubleshooting,maintenance and training service in world wide.
