ZTE ZXCTN9008 PTN 9004 P90-8GE4COC3-SFP Carrier Multi-service Packet Platform ZTE PTN 9000-E
ZTE ZXCTN9008 PTN 9004 P90-8GE4COC3-SFP Carrier Multi-service Packet Platform ZTE PTN 9000-E
ZTE ZXCTN9008 PTN 9004 P90-8GE4COC3-SFP Carrier Multi-service Packet Platform ZTE PTN 9000-E
ZTE ZXCTN9008 PTN 9004 P90-8GE4COC3-SFP Carrier Multi-service Packet Platform ZTE PTN 9000-E
ZTE ZXCTN9008 PTN 9004 P90-8GE4COC3-SFP Carrier Multi-service Packet Platform ZTE PTN 9000-E
ZTE ZXCTN9008 PTN 9004 P90-8GE4COC3-SFP Carrier Multi-service Packet Platform ZTE PTN 9000-E
Specifications
Model Number :
ZTE ZXCTN 9000
Place of Origin :
China
Brand Name :
Huawei
Number name :
ZXCTN P90-8GE4COC3-SFP
Products Status :
Stock
Certification :
CE FCC RoHS
Voice protocol :
SIP,H.248 for option
Packaging Details :
Export carton package
Port :
Shenzhen
Supply Ability :
200 Piece/Pieces per Week
Price :
Negotiable
MOQ :
Negotiable
Delivery Time :
7-15 days
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Description

ZTE ZXCTN9008 PTN 9004 P90-8GE4COC3-SFP Carrier Multi-service Packet Platform ZTE PTN 9000-E

Contact Us

ZTE ZXCTN9008 PTN 9004 P90-8GE4COC3-SFP Carrier Multi-service Packet Platform ZTE PTN 9000-E

ZXCTN 9000-E series is new-generation Carrier class Multi-service Packet-based Platform (CMPP) promoted by ZTE to keep with the development trend of IP telecommunication services. Base on IP/MPLS and MPLS-TP, they implement multi-service bearing and provide customers with IP RAN, Metro-E, and FMC end-to-end solution. They help customers to reduce network building cost and maintenance cost, and assist carriers to realize smooth network evolution.ZTE ZXCTN9008 PTN 9004 P90-8GE4COC3-SFP Carrier Multi-service Packet Platform ZTE PTN 9000-EZTE ZXCTN9008 PTN 9004 P90-8GE4COC3-SFP Carrier Multi-service Packet Platform ZTE PTN 9000-EZTE ZXCTN9008 PTN 9004 P90-8GE4COC3-SFP Carrier Multi-service Packet Platform ZTE PTN 9000-E

Product Feature

Unified Multi-service Bearing Has Rich Service Features

  • Support high bandwidth interfaces as 10GE, 40GE, and100GE,satisfing the high bandwidth requirements of 4G.
  • Based on full-packet architecture, ZXCTN 9000-E adopts PWE3 emulation which is compatible with TDM and ATM. It supports highly efficient MPLS tunnel technologies and L2/L3 VPN, completely meets all-service development demands, and reduces network TCO.
  • Comprehensive MPLS VPN protocols: Support BGP/MPLS VPN, VPWS, VPLS, HoVPN, H-VPLS, L2/L3 VPN Bridge, TDM service emulation, E-Line, E-LAN, and E-TREE services bearing to satisfy multi-service access and transmission.
SpecificationsModelsZXCTN 9000-18EZXCTN 9000-8E PLusZXCTN 9000-8EZXCTN 9000-5EZXCTN 9000-3EZXCTN 9000-2E10ZXCTN 9000-2E4 PlusZXCTN 9000-2E4
Capability
Service Slots1888532×LPC,2×LPC,2×LPC,
8×LIC4×LIC2×LIC
Main Control Redundancy1:011:011:011:011:011:011:011:01
Switch Fabric Redundancy6+23+13+11+1NANANANA
Physical
Rack Unit41RU22RUDC: 14RUDC: 7RUDC: 4RUDC: 5RUDC/AC:4RUDC: 3RU
AC: 18RUAC: 8RUAC: 5RUAC: 6RU
Dimensions1819.6×442×634971.5×442×678.7DC:619.5×442×749.4DC:308.3×442×740DC:175×442×738DC: 219.4×442×220DC/AC: 175×442×220130.5×442×220
(H×W×D)mmAC external: 797.3×442×749.4AC:352.8×442×740AC:219.4×442×738AC: 263.9x442x220
Weights(kg)<357kg<140kg<127kg<81kg<53kgDC:<21kgDC: <15.5kg<14.9kg
AC:<26.5kgAC: <16.8kg
Service Features
SynchronizeSynchronous Ethernet (SynE), IEEE 1588v2
L2EthernetStatic MAC, Dynamic MAC, SuperVLAN, Smart Group, VLAN, QinQ
POS/CPOSHDLC, PPP, FR
ATMATM
E1/CE1PPP, FR, ML-PPP, CES
IP RoutingIPv4 UnicastARP/ARP Proxy, Static Route, Policy Based Routing, RIPv1/v2, OSPFv2, IS-ISv4, BGP-4, ECMP
IPv4 MulticastStatic Multicast, IGMP Snooping/Proxy, IGMP v1/v2/v3, PIM-DM/SM/SSM, MSDP, MBGP, Multicast VPN, Controllable Multicast, Policy Based Route (PBR) for Multicast, Graceful Restart for PIM, Multicast Load Balance
IPv6 UnicastStatic Routing for IPv6, DNS Client v4/v6, Policy Based Routing for IPv6 (PBRv6), RIPng, OSPFv3, IS-ISv6, BGP-4+, ECMPv6
IPv6 MulticastStatic Multicast, MLDv1/v2, PIM-DM/SM/SSM, SSM-Mapping, MBGP
IPv4/IPv6 Interaction6in4, 6to4, GRE
MPLS & Traffic EngineeringMPLS BasicLDP, LDP FRR, Load-Sharing
MPLS VPNVPLS, H-VPLS, VPWS, MS-PW, Inter-AS MPLS L2VPN, Inter-AS MPLS L3VPN option A/B/C, VRF Policy Routing, 6PE/6vPE
MPLS-TEOSPF TE, IS-IS TE, RSVP-TE, DS-TE, Inter-AS/Area TE, TE FRR
High Availability(HA)NSF for IGP/BGP/LDP/RSVP/PIM, NSR for IGP/BGP/LDP, IP FRR, LDP FRR, TE FRR for IP/VPN/VLL/VPLS, VPN FRR, PW Redundancy, VRRP
SecurityACL, uRPF, MAC Filtering, TCP Control, Port Mirror/Flow Mirror, SSHv2, Netflow, Broadcast Storm Suppression, MD5, IPSec
SDN EvolutionOpenflow, Netconf
OAMEthernet OAMIEEE 802.1ag, IEEE 802.3ah, ITU-T Y.1731
MPLS OAMVPLS MAC Ping, MPLS Ping/Trace Route
BFDBFD for Static Routing/Policy Routing, BFD for OSPF/IS-IS/BGP, BFD for VRRP/FRR, BFD for LDP
NMSNetNumen U31, CLI, Telnet, SNMP based GUI, RMON, Syslog, NTP
Power Supply
DCWorking Voltage(DC)DC: -72V~-38VDC: -72V~-38VDC: -72V~-38VDC: -72V~-38VDC: -72V~-38VDC: -72V~-38VDC: -72V~-38VDC: -72V~-38V
Power Redundancy(DC)DC: 11+1DC: 5+1DC: 2+2DC: 1+1DC: 1+1DC: 1+1DC: 1+1DC: 1+1
ACWorking Voltage(AC)AC: 90V~286VAC: 90V~286VAC: 90V~264VAC: 90V~264VAC: 90V~264VAC: 90~286VAC: 90~286VNA
HVDC: 192V~400VHVDC: 192V~400VHVDC: 216V~312VHVDC: 216V~312VHVDC: 216V~312V
Power Redundancy(AC)AC: 8+8AC: 4+4AC: 3+3 | 2+2AC: 1+1AC: 1+1AC: 1+1AC: 1+1NA
Environments
Working Temperature-5~45°C-5~45°C-5~45°C-5~45°C-5~45°C-15~55°C-15~65°C-15~65°C
(Naked)(Naked)(Naked)
-40~50°C-40~55°C-40~55°C
(With Outdoor Cabinet)(With Outdoor Cabinet)(With Outdoor Cabinet)
Working Humidity5%~90%5%~90%5%~90%5%~90%5%~90%5%~95%
Warranty

ZTE ZXCTN9008 PTN 9004 P90-8GE4COC3-SFP Carrier Multi-service Packet Platform ZTE PTN 9000-E

Return Material Authorization (RMA) Process

Standard Hardware Warranty Policy:

Original new sealed ZTE product: 1 Year

The Support Contacts:

If your ZTE products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.

Delivery

Cargo will be delivered within 1 day after payment arrived. Tracking Number will be offered once delivery done.

ZTE ZXCTN9008 PTN 9004 P90-8GE4COC3-SFP Carrier Multi-service Packet Platform ZTE PTN 9000-E

ZTE ZXCTN9008 PTN 9004 P90-8GE4COC3-SFP Carrier Multi-service Packet Platform ZTE PTN 9000-E

Company profile

Uonel is one of the biggest Network Hardware distributor in china, founded in 2008. We are a global provider of netwotking products with more than 5000 customers.

We provide original new Huawei & ZTE & Cisco & Fiberhome & H3C & Ericsson & Alcatel Lucent & Emerson with Routers,Switches,Firewalls,Wireless APs & controllers,OLTs,GPON modems,optical transceivers.we can provide Plenty of Stock, Fast Delivery, Better price, and original guarantee.

Most of our technical engineers has considerable experience in company,we can provide network design&planning,configration,troubleshooting,maintenance and training service in world wide.
