ZXHN F600 is a GPON Optical Network Terminal designed for FTTH scenario. It provides subscribers rich, colorful, individualized, convenient and comfortable services including video (IPTV) and high speed internet access. It has a small, smart appearance and green, energy-saving advantage.
The F600W is an indoor optical network unit(ONu) in ZTE FTTH solution. By using the GPON technology, ultra-broadband access is provided for home and SOHO users. The F600W provides two POTS ports,four GE/FE auto-adapting Ethernet ports and one CATV port. The F600W features high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and HD video services.
ZTE F600W: GPON 4GE+WIFI With external antenna
ZTE F660: GPON 4GE+2PHONE+WIFI+USB with external antenna
ZTE F400G: GEPON 4GE
ZC-502W: GPON 1GE+1FE+WIFI With external antenna
ZC-504W: GPON 1GE+3FE+WIF with external antenna
GPON Interface | Optical port: 1 x GPON interface (SC/PC) |
Transmission Distance: 0 ~ 20km | |
Transmit rate: 2.488Gbps downstream; 1.244Gbps upstream | |
User Network Interface | 4 x10/100/1000Base-T |
Half/full duplex; Auto MDI/MDIX; Auto negotiation | |
Optical Module | Receiving: 1480~1500 nm |
Transmitting: 1290~1330 nm | |
Receiving Sensitivity: -28dBm | |
Transmitting Optical Power: 0.5~5dBm | |
Main Function | Supported service: Internet, IPTV |
GPON: 8 T-CONTs, 32 GEM Ports | |
VLAN: 802.1Q, 802.1P, 802.1ad | |
MAC address table: 256 | |
Multicast: IGMP v1/v2/v3 Snooping | |
Multicast group: 256 | |
QoS: service flow classification based on physical port, Ethernet type; ingress rate limit;egress shaping | |
Management: local web management, OMCI | |
Physical Performance | Power consumption: <6W |
Dimensions: 199mm(W) x 35mm(H) x150mm(D) | |
Working temperature: 0℃ ~ 40℃ | |
Working humidity: 5% ~ 95% | |
Weight: about 260g | |
Power supply: 12V DC | |
Mounting mode: Desktop/Wall mounting | |
Supports hidden and coiled fiber |
Return Material Authorization (RMA) Process
Standard Hardware Warranty Policy:
Original new sealed ZTE product: 1 Year
The Support Contacts:
If your ZTE products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
Cargo will be delivered within 1 day after payment arrived. Tracking Number will be offered once delivery done.
