Specifications
Model Number :
ZXA10 F643 ONU
Type :
Fiber fusion splicer, ZTE OUN
Place of Origin :
China
Brand Name :
Huawei
Product name :
ZTE F643 GPON ONT ONU Device
Application :
FTTH FTTB FTTX FTTC Network Access Equiment
Model Name :
ZXA10 F643 ONU
Brand Name: :
ZTE
Packaging Details :
Export carton package
Port :
Shenzhen
Supply Ability :
200 Piece/Pieces per Week
Price :
Negotiable
Certification :
CE FCC RoHS
MOQ :
Negotiable
Delivery Time :
7-15 days
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Description

Brand New ZTE ZXHN F643

Optical Network Termimal

Contact Us

Brand New ZTE ZXHN F643 Optical Network Termimal F601 upgrade to F643

ZXHN F601 is a GPON Optical Network Terminal designed for FTTH scenario. It provides high-performance forwarding capabilities to ensure excellent experience with Internet and HD video services. It has a small, smart appearance and green, energy-saving advantage.

Brand New ZTE ZXHN F643 Optical Network Termimal F601 upgrade to F643

Product Feature

Original ZXHN F643 1GE GPON ONU ZTE F643

Model

Configuration

Dimension/pcs

LAN

Telephone

Wifi

PPPOE

Firmware

F643(v6.0)

1GE

no

no

no

English

167*140*58mm/0.28kgs

Remarks

Replace F601(v6.0)

Application and Advantage:

ZXHN F643 is a GPON Optical Network Terminal designed for FTTH. It provides high-performance forwarding capabilities to ensure excellent experience with Internet and HD video services. It has a small, smart appearance and green, energy-saving advantage.

The specification of F643 (v6.0):

GPON Interface

Optical port: 1 x GPON interface (SC/PC)

Transmission Distance: 0 ~ 20km

Transmit rate: 2.488Gbps downstream; 1.244Gbps upstream

User Network Interface

1 x10/100/1000Base-T

Half/full duplex; Auto MDI/MDIX; Auto negotiation

Optical Module

Receiving: 1480~1500 nm

Transmitting: 1290~1330 nm

Receiving Sensitivity: -28dBm

Transmitting Optical Power: 0.5~5dBm

Main Function

Supported service: Internet, IPTV

VLAN: 802.1Q, 802.1P, 802.1ad

MAC address table: 256

Multicast: IGMP v1/v2/v3 Snooping

Multicast group: 256

QoS: service flow classification based on physical port, Ethernet type; ingress rate limit;egress shaping

Management: local web management, OMCI

Physical Performance

Power consumption: <3W

Working temperature: 0℃ ~ 40℃

Working humidity: 5% ~ 95%

Power supply: 12V DC

Mounting mode: Desktop/Wall mounting

The setup interface is in English language.
