W2PSA0580 580W AC Power Module
W2PSA0580 580W AC Power Module
W2PSA0580 580W AC Power Module
W2PSA0580 580W AC Power Module
W2PSA0580 580W AC Power Module
W2PSA0580 580W AC Power Module
Specifications
Model Number :
OLT
Place of Origin :
China
Port :
shenzhen
Supply Ability :
200 Piece/Pieces per Week
Price :
Negotiable
Brand Name :
Huawei
Certification :
CE FCC RoHS
MOQ :
Negotiable
Packaging Details :
Export carton package
Delivery Time :
7-15 days
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Description

W2PSA0580 580W AC Power Module

Contact Us

W2PSA0580 580W AC Power Module

Product Feature

580 W AC PoE Power Module
Product Support

Table 1 lists the switch models supporting a 580 W AC PoE power module.

Table 1 Product support for a 580 W AC PoE power module

Power Module Name

Product Support

W2PSA0580

S5710-52C-PWR-EI, S5710-28C-PWR-EI-AC, S5710-52C-PWR-EI-AC, S5720-56C-PWR-HI-AC1

S6720-32C-PWH-SI-AC, S6720-32C-PWH-SI, S6720-56C-PWH-SI-AC, S6720-56C-PWH-SI

Appearance

Figure 1 Appearance of the 580 W AC PoE power module

Function

Table 2 describes the functions of a 580 W AC PoE power module.

Table 2 Functions of a 580 W AC PoE power module

Function

Description

PoE power supply

Provides a maximum of 380 W PoE power.

Input protection

Input overcurrent and undervoltage protection is provided.

Output protection

Output overvoltage, overcurrent, and short-circuit protection is provided.

Overtemperature protection

When the temperature of the power module exceeds a specified threshold (75°C), the power module stops supplying power. When the temperature falls into the normal range, the power module automatically resumes power supply.

Hot swap

Supported

NOTE:

When a power module enters overtemperature protection state, take measures to lower the ambient temperature. The power module can automatically resume power supply when the temperature falls within the normal range.

Panel Description

Figure 2 Panel of a 580 W AC PoE power module

1. Power status indicator

2. Handle

3. Fan

4. Switch

5. AC power socket

6. Captive screw

7. AC power cable locking strap

-

Table 3 describes indicators on a 580 W AC PoE power module panel.

Table 3 Description of indicators on a 580 W AC PoE power module panel

Specifications

Table 4 describes technical specifications of a 580 W AC PoE power module.

Table 4 Technical specifications of a 580 W AC PoE power module

Item

Description

Dimensions (W x D x H)

100 mm x 205 mm x 40 mm (3.9 in. x 8.1 in. x 1.6 in.)

Weight

< 1.6 kg (3.53 lb)

Rated input voltage range

100 V AC to 240 V AC, 50/60 Hz

Maximum input voltage range

90 V AC to 290 V AC, 47 Hz to 63 Hz

Input current

9 A to 4.5 A

Maximum output current

+12 V: 16.66 A

-53.5 V: 7.11 A

Maximum output power

PoE: 380 W

Total: 580 W

Part number

02130953
