100mm Panel Medium Temperature Cool Storage Room With Chiller Unit

Introduction

Cool storage room is a type of refrigeration equipment. Cold storage refers to the use of artificial means to create an environment different from the outdoor temperature or humidity, and it is also a constant temperature and humidity storage equipment for food, liquid, chemical, pharmaceutical, vaccine, scientific experiments and other items. Cool storage room is usually located near the shipping port or origin. Compared with refrigerators, cold storage has a larger cooling area and has a common cooling principle.

Medium temperature cool storage room at 0~10 degrees Celsius are generally used to store fresh vegetables, fruit, meat, fish, flower, etc. If the product is precooling before entering the cold room, the quality and storage time of the product can be extended. If the product has not been precooling in advance, then the cooling capacity of the cold room needs to be designed to be larger in order to cool the product as soon as possible. It is generally recommended that the daily input volume should not exceed 10% of the design storage capacity of the storage room. If the 10% value is exceeded, the temperature in the cold room rises and it is difficult to cool down quickly, which affects the quality of the product.

How To Use Cold Storage Room

The design of the cold storage should meet the technological requirements and be equipped with automatic temperature recorders and thermometers.

Only qualified raw materials or finished products can be put into storage.

Materials are stored and shipped according to the first-in-first-out principle to avoid long-term backlogs that affect quality.

Raw materials and finished products are stored in separate warehouses, and products with mutual odor cannot be stored in the same cold storage.

The temperature of the finished product warehouse, cold storage, and packaging room meets the process requirements. The temperature of the finished product cold storage is below -18°C, the temperature of the quick freezer is below -30°C, and the temperature of the single freezer is below -35°C. The temperature of the cold storage is monitored by the warehouse manager and recorded every 2 hours in the "Refrigerator Temperature Monitoring Record".

The products in the warehouse must have complete packaging, and random stacking is prohibited; the stacking is neat, the batches are clear, and each batch and each stack of products are marked; products, raw materials, and finished products that have cross-flavors are not allowed to be stored in the same inventory.

The distance between the items in the warehouse and the wall is not less than 30cm, and the distance from the ground is not less than 10cm. Keep a certain distance from the ceiling and store them in stacks. Do not stack goods underneath.

Different varieties of products are stored in separate stacks, the batches are clear, and each batch of each stack of products is marked.

The cold storage and finished product warehouse are regularly cleaned and disinfected, and the frost is swept every seven days; the cold storage is cleaned and disinfected at least once a year.

Cool Storage Room With Chiller Unit Picture

Components for Reference

The medium temperature cool storage room is mainly composed of color plate steel storage boards, German compressors, Denmark refrigeration accessories, fans with good heat exchange effects, PLC control electric panels, and precise temperature controllers.

	Panels a.Sandwich type pu panel b.Two sides are color plate steel sheet c.Middle foaming polyurethane (density 40~42kg/m3)		Door a.Manual hinge door b.With emergency open and c.luminescent switch d.Safe when people is locked inside the room
	Compressor Condenser Unit a.Box type, can be placed outdoor b.Germany compressor c.Denmark refrigeration parts d.Low noise + long service life		Evaporator a.Fast cooling speed b.Low consumption c.Electricity or water defrosting
	Control Panel a.Stainless steel case b.PLC control c.Korea or France electric parts d.Automatic operation, automatic frost, alarm		Branded Components a.Expansion valve b.solenoid valve c.Pressure controller d.filter Etc.

Applications

Cold storage room has always been an important part of the logistics industry. Cold storage is mainly used for constant temperature and humidity storage of food, dairy products, meat, aquatic products, poultry, fruits and vegetables, beverages, flowers, green plants, tea, medicines, chemical raw materials, electronic instruments, tobacco, alcoholic beverages and other semi-finished and finished products.

Customer's Usage Case

Our Service

• Project design
• Drawing
• Manufacturing
• On site supervise
• Clients training
• After sales services.

After-sales Services

• 24/7 consults
• 24~72 hours to solve problem
• 1 year warranty
• Life-long maintenance
• Installation: installation and operation manual, online training.

FAQ

1.How can I get quotation?

For professional and suitable quotation, we need to know more information from the end user.

• Products for storage:
• Storage capacity (ton):
• External or internal room size(m or feet):
• Room temperature:
• Daily input capacity (ton):
• Power supply (Voltage/Hz/Phase):
• Installation area/country:
• Does the product finish precooling process before storage?

2.If the products don't do the precooling process, can we put the products into cold storage room or walk in freezer?

• Yes, some customers cannot use pre-cooling equipment due to economic or space problems and directly use cold storage equipment. However, it is recommended that the daily input volume should not exceed 10% of the design cold storage volume.

3.How to install the cold storage room / walk in freezer?

• Huaxian offers operation manual, online installation support service; Customer can find local team to install the cold room / freezer, or Huaxian sends technician to customer's site.

4.What is the payment term?

• By T/T, 30% deposit, the balance will be paid before shipment.
