Environmental Monitoring Duct Type Temperature Sensor RS485
Environmental Monitoring Duct Type Temperature Sensor RS485
Environmental Monitoring Duct Type Temperature Sensor RS485
Environmental Monitoring Duct Type Temperature Sensor RS485
Specifications
Brand Name :
VOTESEN
Model Number :
VTH300-T
Certification :
CE, ROHS
Place of Origin :
China
MOQ :
3
Price :
Negotiable Price
Payment Terms :
T/T
Supply Ability :
35000pcs per day
Delivery Time :
7-25 working days
Packaging Details :
Carton
Sensor Chip :
Original Sensirion SHT30 SHT31 SHT35 (Customizable)
Output :
RS485
Application :
HVAC, Environmental Monitoring for Building, Ventilation Control
Power Supply :
DC10-30V
Humidity Measurement Range :
0%RH~100%RH
Temperature Measurement Range :
-40℃~+80℃
Description

The Duct Type Humidity Temperature Transmitter measures temperature and relative humidity in air ducts. The probe filter at the bottom of the duct temperature and humidity sensor is made of 25um high-strength stainless steel material, which can not only ensure the entry of gas molecules but also prevent the entry of dust particles and water droplets. The pipeline installation method is convenient for on-site installation. It adopts anti-interference circuit design and can withstand various strong electromagnetic inter preferences such as on-site inverse. Besides, the equipment adopts waterproof casing design.

Environmental Monitoring Duct Type Temperature Sensor RS485

PRODUCT PARAMETERS

Environmental Monitoring Duct Type Temperature Sensor RS485

Power Supply 10~30V DC

Maximum Power Consumption

 RS485 0.1W

Accuracy

 Temperature ±0.5℃ (25℃)
Humidity ±3%RH (60%RH,25℃)
Transmitter Operating Temperature -20℃~+60℃, 0%RH~80%RH
Probe Temperature Measurement Range -40℃~+60℃
Probe Humidity Measurement Range 0%RH~100%RH

Long-term Stability

 Temperature ≤0.1℃/y
Humidity ≤1%RH/y

Response Time

 Temperature ≤25s
Humidity ≤8s
Output Signal RS485

PRODUCT FEATURES

★ Anti-interference device.

★ Wide voltage power supply range.

★ Durable and dust proof.

★ Flange fitting, easy installation.

★ High quality silicone sealing ring, good sealing between equipment and exhaust duct.

★ Control HVAC system to improve comfort and energy saving.

★ Original Sensirion SHT humidity temperature chip.

PRODUCT APPLICATIONS

★ HVAC

★ Air conditioning

★ Environmental ventilation control

★ Environmental monitoring for building

★ Factory

★ Lab

★ Agriculture

★ Food industry

★ Drying technology

★ Building automation

★ Industrial

HOW TO ORDER?

To customize the most suitable humidity temperature transmitter for your application, kindly let us know your requirements:

1. SHT Sensor Chip:

2. Output:

3. Order Quantity:
