3988 5K NTC Thermistor Sensor Nickel Plated M6 Ring Lug Copper With 50mm Cable
3988 5K NTC Thermistor Sensor Nickel Plated M6 Ring Lug Copper With 50mm Cable
3988 5K NTC Thermistor Sensor Nickel Plated M6 Ring Lug Copper With 50mm Cable
3988 5K NTC Thermistor Sensor Nickel Plated M6 Ring Lug Copper With 50mm Cable
3988 5K NTC Thermistor Sensor Nickel Plated M6 Ring Lug Copper With 50mm Cable
3988 5K NTC Thermistor Sensor Nickel Plated M6 Ring Lug Copper With 50mm Cable
3988 5K NTC Thermistor Sensor Nickel Plated M6 Ring Lug Copper With 50mm Cable
3988 5K NTC Thermistor Sensor Nickel Plated M6 Ring Lug Copper With 50mm Cable
Specifications
Brand Name :
VOTESEN
Model Number :
VTS100
Certification :
CE, ROHS
Place of Origin :
China
MOQ :
10
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
35000 Pcs per Day
Delivery Time :
7-25 Working Days
Packaging Details :
Carton Box
Standard NTC :
R25℃=5KΩ, B25/100=3988K (Customizable)
Operating Temperature :
-40°C ~ 125°C
Application :
Surface Sensing Applications, Water heater, Boiler, 3D Printer, etc.
Theory :
Resistance Sensor
Probe Type :
M6 Ring Lug Probe (Customizable)
Probe Material :
Nickel-Plated Copper (Customizable)
Probe Dimension :
Customizable
Mounting Type :
Free Hanging Mounting
Cable Material :
Silicone Cable (Customizable)
Cable Length :
50mm (Customizable)
Connector :
Wiring Tinning End (Customizable)
OEM :
Acceptable
Package :
Standard Export Packages
Warranty :
1 Year
Description

VOTESEN VTS100 series NTC Thermistor Temperature Sensors employ NTC sensor elements and feature mechanical protection in different packaging technologies and integrated connectors. Thanks to the robust design and excellent performance, our NTC Temperature Sensors can suitable for the most demanding temperature sensing applications, such as Surface Sensing Applications, Water heaters, Boiler, 3D Printer, etc. Our VOTESEN VTS100 Series NTC Temperature Sensors are the best when it comes to accuracy, precision, and durability. Standard technical parameters make these NTC Temperature Sensors ideal for field use.

PRODUCT PARAMETER

NTC Thermistor 5K 3988 Nickel-Plated Copper M6 Ring Lug Probe Temperature Sensor is a Nickel-Plated Copper Ring Lug Probe for surface temperature control, made with silicone cable. It features a step-down tip design to get temperature precisely and quickly, which is used to monitor the surface temperature. This allows users to be sure the equipment is at the desired temperature and has a better performance.

Standard NTC R25℃=5KΩ, B25/100=3988K (Customizable)
Theory Resistance Sensor
Resistance 5KΩ/10KΩ/20KΩ/50KΩ/100KΩ/230 KΩ/1000KΩ (Customizable)
B Value 3270K/3380K/3470K/3550K/3700K/3950K/4200K/4537K/4250K/4267K/4650K (Customizable)
Operation Temperature -40°C ~ 125°C
Accuracy ± 1%
Thermal Response Time 5~15s
Probe Type M6 Ring Lug Probe/Flange Probe/Thread Probe/Ring Lug/Epoxy (Customizable)
Probe Material Nickel-Plated Copper/Stainless Steel/Nickel-Clad Copper/ Copper/Plastic/Aluminum/Alloy/ABS/PVC/Epoxy/Glass (Customizable)
Probe Dimension Customize according to your requirements
Probe Protection IP68
Mounting Type Free Hanging Mounting
Cable Material Silicone Cable/Fiberglass Cable/Stainless Steel Braided/PTFE/Silicone/TPE/PVC (Customizable)
Cable Length Customize according to your requirements
Connector Wiring Tinning End/Stripped Soldered/XH/Wiring Tinning End/Molex/JST/DuPont/CWB/CJT/PH/Micro-Fit 3.0/RJ11/RJ45/RJ50/3.5mm Stereo Plug/2.5mm Mono Jack (Customizable)
Application Surface Sensing Applications, Water heater, Boiler, 3D Printer, etc.

PRODUCT FEATURE

★Custom Made Available

★Good Stability

★Easy Mounting

★Super Quality

★Small Body Size

★Fast Response

★Epoxy Resin Provides Voltage Insulation

★CE and RoHS Compliant

★ Waterproof

★ Good Interchange Capability

★ Long Lifespan with Stable Performance

★ Excellent Thermal Cycle Endurance

★ Excellent Tolerance and Interchangeability

PRODUCT APPLICATION

Our Votesen NTC Thermistor 5K 3988 Nickel-Plated Copper M6 Ring Lug Probe Temperature Sensor is made with a glass sealed NTC thermistor, which has a fast response time and wide operating temperature range. The thermistors use lead-alloy technology to ensure long-term stability. The Nickel-Plated Copper M6 Ring Lug Probe is suitable for surface sensing applications, especially when good electrical insulation and good thermal contact with the chassis is required.

HOW TO ORDER?

We can customize your NTC products according to your demand. We produce all kinds of special requirements of standard and non-standard temperature sensors and provide OEM and technical support. If you are unsure of the type of thermistor sensor or assembly that fits your requirements, kindly provide us the following information for custom made NTC temperature sensors:

★ Operation Temperature Range

★ Resistance Value

★ B Value

★ Application

★ Probe Type/Shape & Dimension

★ Cable Material

★ Cable Length

★ Connector

★ Sample Order Quantity

★ Bulk Order Quantity

If there is a specific request or custom made, you are welcome to provide us your detailed drawing. Feel free to connect with us!
