Stainless Steel 304 Frame HEPA Filter FFU For Biosafety Cabinet
Stainless Steel 304 Frame HEPA Filter FFU For Biosafety Cabinet
Stainless Steel 304 Frame HEPA Filter FFU For Biosafety Cabinet
Stainless Steel 304 Frame HEPA Filter FFU For Biosafety Cabinet
Stainless Steel 304 Frame HEPA Filter FFU For Biosafety Cabinet
Stainless Steel 304 Frame HEPA Filter FFU For Biosafety Cabinet
Specifications
Place of Origin :
Sichuan, China
Brand Name :
TRAIRF
Packaging Details :
1.FCL Order Filter packaged by 5 layers carton case
2.LCL order filter packaged by wooden case
3.CUSTOMIZATION
Supply Ability :
1000 Unit/Units per Month International Standard Hepa Filter Fan Unit for Biosafety Cabine
Price :
$190.00/units 1-9 units
Payment Terms :
L/C, D/A, D/P, , T/T, Western Union, MoneyGram
Delivery Time :
2-30days
Product name :
Customize Hepa Filter Fan Unit for Biosafety Cabinet
Applicable Industries :
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising C
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Construction :
Box Filter
Dimension(L*W*H) :
1170*570*340mm
Frame material :
Stainless Steel 304
Filter media :
Fiberglass
Feature :
Long Service Life,High performance
MOQ :
50
Description

Customize Hepa FFU Unit For Biosafety Cabinet

OVERVIEW:

Custmize Hepa Filter Fan Unit (FFU) is a of type of motorized air filtering equipment. It is used to supply purified air to clean-rooms, laboratories, medical facilities or micro environments by removing harmful airborne particles from recirculating air.

Fan filter unit hepa filter is installed within the system's ceiling or floor grid. Large clean-rooms require a proportionally large number of FFUs, which in some cases may range from several hundred to several thousand.

Biosafety cabinet fan filter unit often contains their own pre-filter, Air Handling Unit Air Filter and internally controllable fan air distribution.Besides, our company provides all kinds of air filters for industrial filtration system,such as Clean Room Filter Fan Unit Supplier.

SPECIFICATIONS:

Model

Parameters

TR-FFU-F1

TR-FFU-F2

TR-FFU-F3

TR-FFU-F4

TR-FFU-F1X

TR-FFU-F2X

TR-FFU-F3X

TR-FFU-F4X

Nominal volume (m³/h)

2000

1800

1000

900

NoiseDb(A)

54~60

Hepa filter efficiency

≥99.99% ~ 99.9995%( @≥0.3μm)

Power

AC220V±10%,1φ,50HZ±2HZ

The input power (W)

180

180

145

75

Envelop dimensions

(mm)L*W*H

1220*610*390

1170*570*340

610*610*390

570*570*340

Hepa filter specifications

(mm)

1220*610*69

1170*570*69

610*610*69

570*570*69

Coarse efficiency filters specifications

(mm)

495*495*21

495*495*21

395*395*21

395*395*21

Advantages:

1. Long service life.
2. Lower noise and small vibration.
3. Light weight for easy handling.
4.Low energy consumption and environmental-friendly.
5. Attractive appearance and user-friendly design.
6.Maintanance-free.

Applications:

Biosafety cabinet,Clean rooms,Biomedical,Vehicles,Airlines,Heating, air conditioning,spray booth,hospitals,food industry,pharmaceutical industry, universities,laminar flow hood, bio-engineering,respiratory protection, industrial processes, building ventilation systems, Whole House Air Cleaning Systems, Electronic Air Filters for High-End Residential & Commercial Facilities.
