QTZ4807 Hydraulic Telescopic Climbing Types of Tower Crane 48M Working Jib
QTZ4807 Hydraulic Telescopic Climbing Types of Tower Crane 48M Working Jib
QTZ4807 Hydraulic Telescopic Climbing Types of Tower Crane 48M Working Jib
QTZ4807 Hydraulic Telescopic Climbing Types of Tower Crane 48M Working Jib
Specifications
Brand Name :
AVITT or others
Model Number :
QTZ40(4807) Tower Crane
Certification :
CE, ISO, GOST, CU-TR
Place of Origin :
China
MOQ :
1
Price :
$26200-27800 per set
Payment Terms :
TT, LC
Supply Ability :
40 sets per month
Delivery Time :
about 10 days after receiving the deposit or origin LC
Packaging Details :
Naked packing, 3*40’HQ containers.
Condition :
100% New
Application :
Buildings and projects
Type :
Fixed with tower head
Max. load :
4 t
Jib length :
48 m
Tip. load :
0.7 t
Power supply :
380V/50Hz, 415V/50Hz, 220V/50Hz or according to clients need
Mast section :
1.5*1.5*2.2 m
Main chord :
140*12 mm
After sale service :
Engineers available to service overseas
Description

QTZ4807 Hydraulic Telescopic Climbing Types of Tower Crane 48M Working Jib

Quick Details

1) We are a professional manufacture of construction machineS, have ISO, CE , GOST certification, high quality and competitive price

2) Tower crane is a combination of advanced technologies from home and abroad, it is equipped with a hydraulic self-raising mechanism and frequency-converting slewing mechanism.

3) The crane has a complete set of safety devices, which can guarantee the safety and high efficient operation of the equipment, It is equipped with height limiter, moment limiter, radius-changing limiter and weight limiter, etc.

4) Our products have been exported to many countries and areas in Europe, America, Australia, the Middle East and Southeast Asia etc.

Specification

Rated Lifting Moment (KN.M) 400
Type Fixed with tower head
Rated Loading Capacity (t) 4
Max. Lifting Load (t) 4
Tip Load (t) 0.7
Max. Lifting Height (m) 120
Free standing height (m) 29
Rope length (m) 320
Span (m) 48
Working range (m) 3 to 48
Slewing speed (r/min) 0.7/0.35
Trolley peed (m/min) 38.6/25.2
Jacking-up speed (m/min) 0.4
Counter jib length (m) 12.89
Power supply 380V/50Hz or according to client's requirements
Power Capacity (kw) 24.9
Electric switch box Schneider
Hoisting speed (m/min) (a=2) 64.15/32.57/7.0; (a=4) 32.14/15.60/3.5
Mast section (m) 1.5*1.5*2.2m (140*12 /angle steel /Q235B)

Competitive Advantage

1. Focusing on tower crane exporting for 15 years;

2. Preferential ex-factory price, excellent product quality and good after-sales service are our pursuit;

3. Our tower cranes had exported to more than 20 countries, such as Vietnam, Philippines, Indonesia, India, Sri Lanka, Cambodia, Russia, Kazakhstan, Brazil, Cyprus, Belgium, Madagascar and Algeria etc.

4. Factory visit is welcomed.

5. If you need, engineers will go to the construction site for guiding the installation and test-running.

6. Easy-worn Spare parts are free supplied along with the tower crane.

7. 12 months super long time guarantee period.

If any question about tower crane, please do not hesitate to contact us.

QTZ4807 Hydraulic Telescopic Climbing Types of Tower Crane 48M Working JibQTZ4807 Hydraulic Telescopic Climbing Types of Tower Crane 48M Working Jib
