PT6518 65M Jib Boom 10tons Load Top Less Head Tower Cranes Potain Mast
PT6518 65M Jib Boom 10tons Load Top Less Head Tower Cranes Potain Mast
PT6518 65M Jib Boom 10tons Load Top Less Head Tower Cranes Potain Mast
PT6518 65M Jib Boom 10tons Load Top Less Head Tower Cranes Potain Mast
PT6518 65M Jib Boom 10tons Load Top Less Head Tower Cranes Potain Mast
PT6518 65M Jib Boom 10tons Load Top Less Head Tower Cranes Potain Mast
Specifications
Brand Name :
HYCM
Model Number :
QTZ180(PT6518) Tower Crane
Certification :
CE, ISO, GOST, CU-TR
Place of Origin :
China
MOQ :
1
Price :
$132500-140700 per set
Payment Terms :
TT, LC
Supply Ability :
10 sets per month
Delivery Time :
25 days after receiving the deposit or origin LC
Packaging Details :
Naked packing, 7*40’HQ containers.
Application :
Buildings and projects
Type :
Fixed with tower head
Max. load :
10t
Jib length :
65m
Tip. load :
1.8t
Power supply :
380V/50Hz or according to client's requirements
Mast section :
2*2*3m (split type)
Main chord :
200*20mm
Description

PT6518 65M Jib Boom 10tons Load Top Less Head Tower Cranes Potain Mast


Performance parameters
• Max. jib length: 65m;
• Max. lifting capacity 10t;
• Max. hoisting capacity at jib tip:1.8t;
• Rated lifting moment: 1800 Kn.m;
• Max. freestanding height: 60m; Max. working height of anchored crane: 180m;

Specification

ModelQTZ180 (PT6518) Topless Tower Crane
Working Radius (m)65
Max. Load Capacity (T)10
Tip Load (T)1.8
Free standing height (m)60
Max. Height with anchorages (m)200
Mast Section dimension (m)2×2×3, angle steel 200×20mm

Hoisting
Mechanism

Speed (m/min)(a=2)0-100; (a=4)0-50
Motor power (kw)45

Slewing
Mechanism

Speed (r/min)0-0.6
Motor power (kw)2*5.5

Trolleying
Mechanism

Speed (m/min)0-60
Motor power (kw)5.5

Jacking-up
System

Speed (m/min)0.4
Motor power (kw)7.5
Total Power (kw)61.5


FAQ
Q1: Will you help with installation and stuff training?
Yes,we will send engineers to you and guide the installation and train your workers.
Q2: How do you control thre quality ?
We insisit the "Quality is priority"always pay attention to quailty control from the very the begining to the end .You can also be reassured by our one-year waranty and ISO certiificates
Q3:Where is your factory located ?How can i visit there ?
Our factory is located Zhangqiu city, shandong province, China.
All our cilents- from home and abroad are warmly welcome to visit us!

Safety Devices
a. 3 obstacle lights
b. Height limiter
c. Slewing limiter
d. Range/ trolley limiter
e. Weight limiter
f. Moment limiter
g. Anemometer and block box(optional)

Advantage of Fixed Tower Crane
1. 15 years of experience in supplying new tower cranes.
2. Export to more than 20 countries with CE/ISO/GOST/CU-TR Certificates.
3. Mobile and internal climbing type tower cranes are also available.
4. Impeller blasting and rust protection painting with advanced painting process.
5. Strict and experience welding line
6. New designed mast, can be used to Internal and external climbing tower crane
7. Well known brand mechanism system, Schneider Electronic control system, Jjiangte or Jiuhe motor
8. Engineers available to service machinery overseas.
9. For warranty: 12 months from the B/L date.

Photos
PT6518 65M Jib Boom 10tons Load Top Less Head Tower Cranes Potain MastPT6518 65M Jib Boom 10tons Load Top Less Head Tower Cranes Potain Mast
