2020 NEW TOWER CRANE CAPACITTY 22T QTP8035 TOPLESS TOWER CRANE FACTORY
2020 NEW TOWER CRANE CAPACITTY 22T QTP8035 TOPLESS TOWER CRANE FACTORY
2020 NEW TOWER CRANE CAPACITTY 22T QTP8035 TOPLESS TOWER CRANE FACTORY
2020 NEW TOWER CRANE CAPACITTY 22T QTP8035 TOPLESS TOWER CRANE FACTORY
2020 NEW TOWER CRANE CAPACITTY 22T QTP8035 TOPLESS TOWER CRANE FACTORY
2020 NEW TOWER CRANE CAPACITTY 22T QTP8035 TOPLESS TOWER CRANE FACTORY
Specifications
Brand Name :
HYCM TOWER CRANES
Model Number :
PT8035
Certification :
CE, ISO, GOST, CU-TR
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
30% advance payment and balance before shipment or by copy of B/L or L/C at sight
Supply Ability :
25 sets per month
Delivery Time :
about 58 days after receiving the deposit
Packaging Details :
Naked packing, 40'HQ or 20'GP container.
Max. Load :
22ton
Top Load :
3.5ton
Mast Section Dimension :
2.5*2.5*6m
Freestanding Height :
80m
Power Supply :
380V/50Hz or as per your requirements
Detailed Model :
QTP550(8035) topless tower crane
Type :
2020 New Tower Crane Capacitty 22t QTP8035 Topless Tower Crane Factory
Inverter :
three mechanisms included
Description

2020 New Tower Crane Capacitty 22t QTP8035 Topless Tower Crane Factory

2020 NEW TOWER CRANE CAPACITTY 22T QTP8035 TOPLESS TOWER CRANE FACTORY2020 NEW TOWER CRANE CAPACITTY 22T QTP8035 TOPLESS TOWER CRANE FACTORY2020 NEW TOWER CRANE CAPACITTY 22T QTP8035 TOPLESS TOWER CRANE FACTORY

The Characteristics for 2020 New Tower Crane Capacitty 22t QTP8035 Topless Tower Crane Factory

1. Overall appearance is an international popular type, which is very beautiful and has been very popular among customers both at home and abroad.

2. Trolleying and slewing mechanisms are with high working speed, good speed adjustment features and more stable works.

3. Electrical control system adopts to electrical components supplied by professional electrical factories, which is using advanced foreign technology to produce goods. The service life is 3~4 times longer than that of the domestic components. Less trouble, simple maintenance, reliable work.

Specifications for 2020 New Tower Crane Capacitty 22t QTP8035 Topless Tower Crane Factory

main capacity main data
main load moment (KN.m) 5500
max load (t) 22
tip load (t) 3.5
working radius (m) 3.5-80
lifting height (m) 260
lifting jib upper chord (mm) 140 Round steel / Q345B
lower chord (mm) ∠164X16 Square tube / Q345B
lifting mechanism reducer 75TLQ50
motor YZPF280S-4-75KW
braker YWZ-400/55
steel rope 35W×7-20-1960 -I right lay
lifting speed (m/min) 0-140 0-70
slewing mechanism reducer HP90.160.195
motor YPHW132L2-4-9KW
slewing speed (r/min) 0-0.57
trolley mechanism reducer 11TXB7
motor YZZ132S1-4-11KW
trolley speed ( m/min) 0-78
slewing bearing model 1830.50

Safety devices for 2020 New Tower Crane Capacitty 22t QTP8035 Topless Tower Crane Factory

1. Over load limit
2. Over speed limit
3. Hoist height limit

4. Slewing angle limit
5. Lifting moment limit
6. Wind lock device.

7. Emergency stop button

8. Obstruction light (on the tip of jib and tower head)

Optional Parts for 2020 New Tower Crane Capacitty 22t QTP8035 Topless Tower Crane Factory

1. Anemometer

2. Air condition in the cabin

3. Direct connection motor

4. Block box or anti-collision system or space limiter

Our Service for 2020 New Tower Crane Capacitty 22t QTP8035 Topless Tower Crane Factory

Quality Assurance
Good quality is assured by advanced manufacturing technology. And all products will be checked by our quality-control manager.
The Fastest Reply
Detailed information,specific model and price of products will be provided quickly after receiving inquiry.
Excellent Package
We provide standard, strong, protective package for our products to prevent it from outer damage.
Warranty Assurance
For our tower crane, we provide 1 year (from BL date) warranty period and quick replace service.
