Specifications
Brand Name :
HYCM-Tower CraneS
Model Number :
QTD230(5523) Types of Tower Cranes
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 set of types of tower cranes
Price :
Negotiation
Payment Terms :
30% advance payment and balance before shipment or by copy of B/L OR 100%LC at sight
Supply Ability :
150 pcs of types of tower cranes per month
Delivery Time :
about 55 days after receiving the deposit
Packaging Details :
In nude or as customized, 20'GP or 40'HQ containers for types of tower cranes
Type :
D5523 Luffing Jib Tower Crane 55m Boom Length 12T Load Split Mast Section to Save Containers
Main materials :
200*20 mm/angle steel/ Q345B
Counter jib :
7530mm
Hoisting speed :
0-100 0-50m/min
Power supply :
380V/50Hz or according to your inquiry
Electric switch box :
Schneider
Max. lifting load :
12 tons
Lifting Arm length :
55 meters
Mast section dimension :
2*2*3m/Split structure
Slewing speed :
0-0.57r/min
Freestanding height :
37.5 meters
Attaching height :
260 meters
Tip Load :
2.3 tons
Trolleying mechanism Reducer Motor Trolleying speed :
0-10 m/min
Description

D5523 Luffing Jib Tower Crane 55m Boom Length 12T Load Split Mast Section to Save Containers

Specifications for D5523 Luffing Jib Tower Crane 55m Boom Length 12T Load Split Mast Section to Save Containers
Main Performance Main Specifications
Rated lifting moment (KN.m) 2300
Max. lifting load(t) 12
Tip load(t) 2.3
Working range(m) 5~55
Lifting height(m) Freestanding height 37.5
Attaching height 260
Mast section Main limb (mm) ∠200*200*20/ Q345B
Section size(mm) 2000*2000*3000
Lifting jib Upper chord(mm) 80*8 Square tube /Q345B
Lower chord(mm) 100*8 Square tube /Q345B
Counter jib Length(mm) 7530
Hoisting mechanism Reducer 45TLQ30
Motor YZTPF225M-4-J13021-45KW
Brake YWZ-315/45
Wire rope 35W*7-16-1960 I right lay
Hoisting speed (m/min) 0-100 0-50
Slewing mechanism Reducer HP90.160.195
Motor YPHW132L2-4-9KW
Slewing speed (r/min) 0-0.57
Trolleying mechanism Reducer 45TLQ25
Motor YZTPF225M-4-J13021-45KW
Trolleying speed( m/min) 0-10
Jacking-up speed

Hydraulic pump station

Jacking oil cylinder

 TQZ230/180/125
Motor 11KW
Slewing bearing Type 1600.45
Photos for D5523 Luffing Jib Tower Crane 55m Boom Length 12T Load Split Mast Section to Save Containers
D5523 Luffing Jib Tower Crane 55m Boom Length 12T Load Split Mast Section to Save ContainersD5523 Luffing Jib Tower Crane 55m Boom Length 12T Load Split Mast Section to Save ContainersD5523 Luffing Jib Tower Crane 55m Boom Length 12T Load Split Mast Section to Save Containers
D5523 Luffing Jib Tower Crane 55m Boom Length 12T Load Split Mast Section to Save ContainersD5523 Luffing Jib Tower Crane 55m Boom Length 12T Load Split Mast Section to Save ContainersD5523 Luffing Jib Tower Crane 55m Boom Length 12T Load Split Mast Section to Save Containers
Description for 55m Lifting Arm 37.5m Height 12ton Luffing Jib Types of Tower Cranes in Cambodia with Form E
1. The Fixed Tower crane base fixed to the ground on a concrete foundation
2. The base is then attached to the mast sections which gives the crane its height.
3. Further the mast is attached to the slewing unit that allows the crane to slewing.
4. The horizontal jib (working arm) is the part of the crane that carries the load.
5. The counter-jib carries a counterweight while the jib suspends the load to and from the center of the crane.
6. The crane operator usually stay in the cabin at the top of the tower.
7. The lifting hook is operated by the operator using electric motors to manipulate wire rope cables through a system of sheaves which lift the building materials
Our Service for 55m Lifting Arm 37.5m Height 12ton Luffing Jib Types of Tower Cranes in Cambodia with Form E
a.Quality Assurance
Good quality is assured by advanced manufacturing technology. And all products will be checked by our quality-control manager.
b.The Fastest Reply
Detailed information,specific model and price of products will be provided quickly after receiving inquiry.
c.Excellent Package
We provide standard, strong, protective package for our products to prevent it from outer damage.
d.Warranty Assurance
For our tower crane, we provide 1 year (from BL date) warranty period and quick replace service.
