Specifications
Brand Name :
Hanjiu
Model Number :
BMSY
Certifiion :
ISO9001
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
30000 Set/month
Delivery Time :
20-30 Days
Packaging Details :
Carton box,Wooden box
Meterial :
Cast iron
Name :
Hydraulic Motor
Model :
BMSY
Appliion :
Hydraulic equipment
Type :
Torqmotor Gerotor
Warranty :
12-18 Months
Original :
Made In China
Quality :
High quality
Description

Hydraulic Motor Hydraulic Orbit Motor BMSY Danfoss Replacement

Product details:

The BMSY series motor adapts the advance Rolortorc™ gear set design with a disc distribution system flow and high pressure. These motors can be supplied with various option sfor multifunctional operations in accordance with the appliion requirements. The output shaft tapered roller bearings permit high axial and radial forces offering a smooth operation during low pressure start up and high pressure operation. The low weight, advanced construction design motors are manufactured in accordance with the requirements of the ISO 9000-2000 quality system

Characteristic featutres:
* Advanced manufacturing devices for the Geroler gear set, which use low pressure of start-up, provide smooth and
reliable operation and high efficiency.
* The output shaft adapts in tapered roller bearings that permit high axial and radial forces. The can offers
capacities of high pressure and high torque in the wide of appliions.
* Advanced design in disc distribution flow, which can automatically compensate in operating with high volume
efficiency and long life , provide smooth and reliable operation.
* The new series motor is suitable for vehicles with greater loads and pressure drop

Appliion:

Mainly used in injection molding machinery, ships, hoists, construction machinery, construction machinery, coal mining machinery, mining machinery, metallurgical machinery, marine machinery, petrochemical industry, port machinery, agricultural machinery, etc.

Specifiions

Technical data for BMSY
Type

BMSY

BMSYS

80

BMSY

BMSYS

100

BMSY

BMSYS

125

BMSY

BMSYS

160

BMSY

BMSYS

200

 BMR
BMRS
250

BMSY

BMSYS

315

BMSY

BMSYS

400

BMSY

BMSYS

475
Geometric displacement (cm3 /rev.) 80.6 100.8 125 154 194 243 311 394 475
Max. speed (rpm) cont. 800 748 600 470 345 300 240 185 155
int. 988 900 720 560 450 360 280 225 185
Max. torque (N·m) cont. 225 290 365 485 586 708 880 880 910
int. 305 390 480 590 705 860 1000 980 990
Max. output (kW) cont. 16 18 18 18.1 18.1 18 17 11 9
int. 20 22 23 25 24 23.8 20.2 12 11
Max. pressure drop (MPa) cont. 20.5 20.5 20.5 21 21 20 20 16 14
int. 27.5 27.5 27.5 26 25 25 24 19 15
peak 29.5 29.5 29.5 28 27 27 26 21 17.5
Max. flow (L/min) cont. 25 75 75 75 75 75 75 75 75
int. 30 90 90 90 90 90 90 90 90
Weight (kg) 9.8 10 10.3 10.7 11.1 11.6 12.3 13.2 14.3

Competitive Advantage

High efficiency

High starting torque
Robust and compact design
High radial and axial bearing capacity
For appliions in both open and closed loop hydraulic systems
Suitable for a wide variety of hydraulics fluids
Smooth running over the entire speed range
Constant operating torque over a wide speed range
Long life under extreme operating conditions
High return pressure without the use of drain line (High pressure shaft seal)

At present, most popular Brands in Hydraulics are Danfoss, Char Lynn, M+S, HANJIU, each with its own merits, however the reason why more and more clients choose HANJIU is because it has obvious advantages over other brands in terms of delivery, service, quality and profit rate.
