HMF Series Heavy Duty Hydraulic Motors Cast Iron Housing High Torque
HMF Series Heavy Duty Hydraulic Motors Cast Iron Housing High Torque
HMF Series Heavy Duty Hydraulic Motors Cast Iron Housing High Torque
HMF Series Heavy Duty Hydraulic Motors Cast Iron Housing High Torque
HMF Series Heavy Duty Hydraulic Motors Cast Iron Housing High Torque
HMF Series Heavy Duty Hydraulic Motors Cast Iron Housing High Torque
Specifications
Brand Name :
HIGHLAND
Model Number :
HMF90
Certification :
PATENT CERTIFICATE
Place of Origin :
CHINA DEZHOU
MOQ :
5 sets
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
140 sets per month
Delivery Time :
10 working days
Packaging Details :
Plywood case
Max.pressure :
42mpa
Model :
HMF90
Type :
Hydraulic components
Features :
Easy maintenance
Application :
Mobile crusher heavy duty hydraulic motors
Medium :
Hydraulic oil
Warranty :
1 year
Function :
Hydraulic system components
Package :
Plywood case
Product name :
HMF Series Hydraulic Motors: Cast Iron Housing,High Torque
Description

HMF Series Hydraulic Motors: Cast Iron Housing,High Torque

Quick Detail:

·Cast iron housing

·Hydraulic components

·Model HMF90

·Hydraulic system power components

·Principle hydraulic transmission

·Features easy maintenance

·Simple layout

·System Solutions

·Work fast

·Fully replace imported products

·Patent certificate certification

·Application mobile crusher heavy duty hydraulic motors

·1 year warranty

Description:

Heavy duty hydraulic motors features:

In the mining industry, where equipment faces extreme conditions and heavy loads, our Heavy Duty Hydraulic Motors are the ideal solution. Designed to power heavy mining machinery, these motors deliver the necessary torque and durability required for efficient and continuous operation in subterranean environments, ensuring consistent performance under rigorous conditions.

HMF Series Technical parameter:

HMF hydraulic pump and HMF hydraulic motor series 30 50 70 90 110 130
Displacement Max displacement ml/r 30 50 70 90 110 130
Speed Max continuous working speed
(Full load condition)		 r/min 3500 3500 3200 3200 2900 2900
Rated speed r/min 2500
Min continuous working speed r/min 500
Pressure Rated working pressure Mpa 35
Max working pressure (transient) Mpa 42
Continuous working pressure Mpa 30
Allowable shell pressure (Absolute) Mpa Constant0.25, Peak value0.5
Torque Continuous output torque
(Under continuous working pressure)		 Nm 162.3 252.3 342.6 432.9 535.3 632.4
Max output torque Nm 227 353 480 606 749 885
Power Continuous output power KW 45 79 107 139 149 176
Max power KW 62 95 114 150 173 205
Temperature Allowable shell temperature ℃ 80
Max working temperature of oil tank ℃ 70
weight HPV series hydraulic pump hydraulic oil drain kg 45 46 63 64 82 88
HPV series hydraulic motor hydraulic oil drain kg 30 30 36 36 36 38

HMF Series Heavy Duty Hydraulic Motors Cast Iron Housing High Torque

Notices:

Continuously monitor the system pressure levels of your Heavy-Duty Hydraulic Motors. Excessive or inconsistent pressure can lead to operational issues and potential damage. Implementing pressure relief valves and regular checks can prevent such problems, ensuring the motors operate within safe and optimal pressure ranges.

HMF Series Heavy Duty Hydraulic Motors Cast Iron Housing High Torque

Application:

Mixer truck: concrete mixer truck, cement mixer truck;

Coal mining machinery: scraper;

Industry: pharmaceutical machinery;

Transport vehicles: road rollers, concrete pump trucks, stabilized soil mixers

HMF Series Heavy Duty Hydraulic Motors Cast Iron Housing High Torque

FAQ

Q1. Can I have a sample order for mobile crusher heavy duty hydraulic motors ?

A: Yes, we welcome sample order to test and check quality.

Q2. What about the lead time?

10 to 15 days for samples, mass production according to MOQ

Q3. Do you have any MOQ limit for mobile crusher heavy duty hydraulic motors ?

A: Low MOQ, 1pc for sample checking is available.

Q4. How do you ship the goods and how long does it take to arrive?

Ship by sea, it generally takes 15-20 days to arrive, and air is also optional.

Q5. How to proceed an order for mobile crusher heavy duty hydraulic motors ?

A: Firstly let us know your requirements or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms the samples and places deposit for formal order.

Fourthly We arrange the production.

Q6: Do you offer guarantee for the products?

A: Yes, we offer 1 years warranty to our products.

Q7: How to deal with the faulty?

A: Firstly, our products are produced in strict quality control system.Secondly, we will inspect the defective pump and motor, and then respond according to the actual situation
