Specifications
Brand Name :
HIGHLAND
Model Number :
HPV110
Place of Origin :
CHINA DEZHOU
Certification :
PATENT and ISO CERTIFICATE
MOQ :
5 sets
Price :
Negotiable price
Packaging Details :
Plywood case with anti-rust treatment
Delivery Time :
According to customers' quantity
Payment Terms :
T/T, Western Union
Supply Ability :
300 sets per month
Function :
Hydraulic System Components
Direction Of Rotation :
Left Or Right Rotation
Max Working Pressure :
42MPa
Medium :
Hydraulic Oil
Material :
Cast Iron
Package :
Plywood Case
Application :
Agricultural Harvester, Tractor Etc
Product Name :
42MPa Agricultural Hydraulic System Components Hydraulic Pumps
Description

42MPa Agricultural Hydraulic System Components Hydraulic Pumps

Product Description:

In order to meet the needs of the agricultural sector, our company has designed and developed a new generaion of agricultural hydraulic variable displacement piston pumps. These pumps have some very desirable features that make them suitable for use in various types of agriculture machinery, such as combine harvesters, forage harvesters, tractors, and other machineries. They offer power drives for different functions, like harvesting, conveying, loading and unloading.

These hydraulic piston pumps are superior in terms of performance, safety and energy efficiency. They can be used in different pressure and flow conditions, easily adapting to different load requirements. This also helps reduce energy consumption, making them highly efficient for agricultural operations. In addition, these pumps are easy to install, maintain, and control.

Features:

  1. Firstly, the axial variable displacement piston pump has a swash plate structure, making it suitable for hydrostatic transmissions with closed-loop circuits. This structure enables manual servo and hydraulic variable control for both variable displacement pumps and fixed displacement motors.
  2. Bearings of Variable Axial Piston Pumps are all tapered roller bearing, which can load heavy external axial forces.
  3. Hydraulic pumps can be connected with other additional pumps.
  4. When Hydraulic pumps operated mechanically, the Servo displacement can control and keep the angle of swash plate and pump displacement.

42MPa Agricultural Hydraulic Pumps For Tractor Hydraulic System Components

Technical Parameters:

HPV hydraulic pump and HMF hydraulic motor series 30 50 70 90 110 130
Displacement Max displacement ml/r 30 50 70 90 110 130
Speed Max continuous working speed
(Full load condition)		 r/min 3500 3500 3200 3200 2900 2900
Rated speed r/min 2500
Min continuous working speed r/min 500
Pressure Rated working pressure Mpa 35
Max working pressure (transient) Mpa 42
Continuous working pressure Mpa 30
Allowable shell pressure (Absolute) Mpa Constant0.25, Peak value0.5
Torque Continuous output torque
(Under continuous working pressure)		 Nm 162.3 252.3 342.6 432.9 535.3 632.4
Max output torque Nm 227 353 480 606 749 885
Power Continuous output power KW 45 79 107 139 149 176
Max power KW 62 95 114 150 173 205
Temperature Allowable shell temperature ℃ 80
Max working temperature of oil tank ℃ 70
Weight HPV series hydraulic pump
hydraulic oil emptying		 kg 45 46 63 64 82 88
HMF series hydraulic motor
hydraulic oil emptying		 kg 30 30 36 36 36 38

42MPa Agricultural Hydraulic Pumps For Tractor Hydraulic System Components

Applications:

Currently, the advances in science and technology have made agricultural hydraulics widely available. Our hydraulic pumps motors make hydraulic farming effortless.

These pumps motors are suitable for a vast array of agricultural equipment, ranging from combine harvesters, tractors, sprayers, track loaders to forage harvesters. It also works well with other kinds of farm machinery.

Support and Services:

Agricultural Hydraulic Pumps Technical Support and Service

We provide technical support and service for our agricultural hydraulic pumps. Our technical support team includes experienced engineers and technicians who are available to help with product selection, troubleshooting, and repair.

A production base of 7000 square meters, independent research and development, production, and factory direct sales.

The company is a manufacturer and service provider of hydraulic systems and components. For more than 20 years since its establishment, the company has been committed to solving the confusion in the field of hydraulics.

42MPa Agricultural Hydraulic Pumps For Tractor Hydraulic System Components

FAQ:

Q: What is the brand name of the Agricultural Hydraulic Pumps?

A: The brand name of the Agricultural Hydraulic Pumps is HIGHLAND.

Q: What is the model number of the Agricultural Hydraulic Pumps?

A: The model number of the Agricultural Hydraulic Pumps is HPV110.

Q: Where is the place of origin of the Agricultural Hydraulic Pumps?

A: The place of origin of the Agricultural Hydraulic Pumps is from China Dezhou.

Q: What are the certifications of the Agricultural Hydraulic Pumps?

A: The certifications of the Agricultural Hydraulic Pumps are PATENT and ISO CERTIFICATE.

Q: What is the minimum order quantity of the Agricultural Hydraulic Pumps?

A: The minimum order quantity of the Agricultural Hydraulic Pumps is 5 sets.
