42 Mpa Hydraulic Pump Test Stand , Hydraulic Testing Gauges Computer Control
42 Mpa Hydraulic Pump Test Stand , Hydraulic Testing Gauges Computer Control
42 Mpa Hydraulic Pump Test Stand , Hydraulic Testing Gauges Computer Control
42 Mpa Hydraulic Pump Test Stand , Hydraulic Testing Gauges Computer Control
42 Mpa Hydraulic Pump Test Stand , Hydraulic Testing Gauges Computer Control
42 Mpa Hydraulic Pump Test Stand , Hydraulic Testing Gauges Computer Control
Specifications
Brand Name :
HIGHLAND
Model Number :
YST380
Certification :
CE
Place of Origin :
China Dezhou
MOQ :
1 set
Price :
USD 28800-86800/set
Payment Terms :
T/T
Supply Ability :
5 sets per month
Delivery Time :
30-60 work days
Packaging Details :
Plastic film packaging
Product name :
42 mpa Hydraulic test stand hydraulic pump test stand hydraulic testing gauges
Pressure :
0-42mpa
Loading mode :
Local loading mode and computer control
Flow rate :
0-380 L/min
Range of rotational speed :
0~2250r/min
Drive mode :
Ordinary electric motor
Warranty :
1 year
Motive force :
Electromotor
Medium :
Hydraulic oil
Total power :
0-160kw
Description

42 mpa Hydraulic test stand hydraulic pump test stand hydraulic testing gauges

Hydraulic test bench details:

YST Series hydraulic test stand is used for checking and proofreading the products that include hydraulic pump, motor and valve, it also can give hydraulic system’s breakdown diagnosis. YST series hydraulic test bench are design and manufactured by us, we can produce according customer's requirments.

42 Mpa Hydraulic Pump Test Stand , Hydraulic Testing Gauges Computer Control

Basic Information:

Motive Power: Ordinary electromotor; Frequency conversion electromotor; Hydraulic electromotor; diesel engine drive; diesel engine hydraulic drive

Pressure: 35Mpa; 42Mpa

Power: 7 5KW; 90 KW; 110 KW; 160 KW

Load Location: Local; Long distance

Provide oil: oblige; absorb

Show location: Locale; Computer

Working medium: hydraulic oil

Oil tank cubage: 2000L; 3400L

Oil filtrate: 2 degree filter; 4degree filter; filtrate equipment

Cooling way: wind cooler; water cooler

Accessories: Connect shaft (2 Pc); outline drawing of shaft (1 pc)

Increasing function: close pump test; torsional moment power test

42 Mpa Hydraulic Pump Test Stand , Hydraulic Testing Gauges Computer Control

Technical parameter

Technical Data:

  • YST-500 Hydraulic Comprehensive Test Bench
flow rate power pressure motive force
500L/min 150KW 35Mpa combined electric motor hydraulic drive, stepless speed redulation
  • YST-380 Hydraulic Pump Test Bench
flow rate power pressure motive force
380L/min 75-160KW 35Mpa combined electric motor hydraulic drive, stepless speed regulation
  • YST-380 Digit Hydraulic Test Bench
flow rate power pressure motive force
380L/min 120KW 35Mpa combined diesel engine hydraulic drive
  • YST-300 Digit Hydraulic Test Bench
flow rate power pressure motive force
300L/min 75KW 35Mpa Motor

42 Mpa Hydraulic Pump Test Stand , Hydraulic Testing Gauges Computer Control

Tags:Hydraulic test bench,hydraulic pump test stand hydraulic testing gauges
