MYHT-1-5 Hydraulic Flow Meter Test Kit For Hydraulic Valve Cylinder On -Site Diagnosis
MYHT-1-5 Hydraulic Flow Meter Test Kit For Hydraulic Valve Cylinder On -Site Diagnosis
MYHT-1-5 Hydraulic Flow Meter Test Kit For Hydraulic Valve Cylinder On -Site Diagnosis
MYHT-1-5 Hydraulic Flow Meter Test Kit For Hydraulic Valve Cylinder On -Site Diagnosis
MYHT-1-5 Hydraulic Flow Meter Test Kit For Hydraulic Valve Cylinder On -Site Diagnosis
MYHT-1-5 Hydraulic Flow Meter Test Kit For Hydraulic Valve Cylinder On -Site Diagnosis
Specifications
Brand Name :
HIGHLAND
Model Number :
MYHT-1-5
Certification :
PATENT CERTIFICATE
Place of Origin :
CHINA DEZHOU
MOQ :
1 set
Price :
USD1850/set
Payment Terms :
T/T
Supply Ability :
100 sets per month
Delivery Time :
10 working days
Packaging Details :
Anti-corrosion plastic bag and plywood case
Product model :
MYHT-1-5
Flow range :
0-500l/min
Pressure range :
0-42Mpa
Temperature :
150C
Weight :
10.5kg
Application :
Hydraulic valve and cylinder
Color :
Silver and black color
Product name :
MYHT-1-5 hydraulic flow meter test kit
Description

MYHT-1-5 hydraulic flow meter test kit for hydraulic valve cylinder

Hydraulic flow meter test kit basic information:

MYHT-1-5 hydraulic flow meter test kit accurately measure oil flow, temperature, and pressures against manufacturers' specifications. Temperature flow and pressure readings are displayed by digital display meters, hydraulic test kit is an ideal and practical tool to test hydraulic pump motor, hydraulic valve and hydraulic cylinder. Meantime it has light weight and small volume, which can be brought on site.

Hydraulic flow test kit main features:

1) High precision - scale span ± 1%.

2) Turbine flow sensor - fast response, antipollution, low pressure loss.

3) With fast-measuring, high-accuracy and good-stability

4) Flow and temperature display, using four LED digital tube, free of low temperature limit.

5) Pressure indication: seismic-resistant gauges with super stable and overload ability.

6) Security design, indicators for reverse connection of test gauges, and for pressure, power.

7) Easy operation, flow rate, pressure and temperature can be tested. simultaneously at one point. Pressure valve adjusts with light power, and the loading is smooth and quickly, accurate.

8) Wide Application, compact structure, light weight, pump test, online system test, applicable for rapid diagnosis for all kinds of mobile and fixed hydraulic system and components.

MYHT-1-5 Hydraulic Flow Meter Test Kit For Hydraulic Valve Cylinder On -Site Diagnosis

Hydraulic flow meter test kit technical specifications:

Model Flow(L/min) Precision Pressure(bar) Oil Temperature(°C) Dimensions(mm) Weight(Kg)
MYHT-1-2 200 ±1% 420 150 280*245*172 6.1
MYHT-1-4 400 ±1% 420 150 280*245*172 8.8
MYHT-1-5 500 ±1% 420 150 280*245*172 10.5
MYHT-1-7 800 ±1% 420 150 310*285*261 14

MYHT-1-5 Hydraulic Flow Meter Test Kit For Hydraulic Valve Cylinder On -Site Diagnosis

Usage of MYHT-1-5 hydraulic flow meter test kit :

In the hydraulic loop system, the acquisition of breakpoints data and the measurement of flow rate, pressure and temperature of the system and components are able to be realized simultaneously. Through the data acquired MYHT Tester evaluates the performance of the system and components and judges the faults.

It is widely used in testing and diagnosing for hydraulic pump, hydraulic motor and hydraulic valve, hydraulic cylinder etc hydraulic transimission system.

FAQ of hydraulic flow meters:

Q: Are you a manufacturer or trading company?

A: We are a professional hydraulic tester manufacturer.

Q: What is the MOQ?

A: 1pc is also OK.

Q: How long is your warranty?

A: All our products come with an one (1) year warranty.

Q: Which payment terms could you accept?

A: Payment Terms: T/T , Western Union or Cash .

Q: Is your company accept customization?

A: We have our own factory, and excellent design team,and we accept OEM.

MYHT-1-5 Hydraulic Flow Meter Test Kit For Hydraulic Valve Cylinder On -Site Diagnosis
Tags: hydraulic flow meters, hydraulic flow test kit, hydraulic valve test kit.
