Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure
Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure
Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure
Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure
Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure
Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure
Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure
Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure
Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure
Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure
Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure
Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure
Specifications
Brand Name :
Helm Tower
Model Number :
Rexroth A10V
Certification :
ISO9001
Place of Origin :
Ningbo China
MOQ :
Negotiation
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5000 pieces per month
Delivery Time :
3 days
Packaging Details :
Wooden Case
Package :
Wooden Case
Warranty :
1 Year
Product name :
Hydraulic piston pump
Power :
Hydraulic
Speed :
High Speed
Usage :
Construction Machinery
Color :
According to customer demand
Description

Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure

Features:

A10V variable displacement hydraulic piston pump

Nominal pressure 280Bar, Peak pressure 350Bar;

Swash plate design axial variable piston pump used in open circuit.
Continuous work pressures can reach 280bar; the highest instantaneous work pressure can reach 350bar.
The flow is directly proportional to the drive rotate speed and the displacement, and can make stepless variable come true by adjusting the obliquity of the swash plate.
There are various of control type such as DR, DFR, DFLR etc. and the control response is very fast.
Low noises level, High efficiency, High reliability and long time service life.
Small volume, High power density.
Excellent oil absorbency.
Axial and radial loading of drive shaft possible
SAE and ISO mounting flange

Thru shaft configuration use in circuit system

DR DRF/DRS LA DFE ED (RE 92707)
Pressure controller Pressure and flow controller Pressure, flow and power controller Pressure and flow controller, electronic Electrohydraulic closed-loop pressure control

Specification data:

Type A10VSO16 A10VSO18 A10VSO28 A10VSO45 A10VSO71 A10VSO100 A10VSO140
Sizes 18 18 28 45 71 100 140
Displacement Vg max cm3 18 18 28 45 71 100 140
Max speed nmax rpm 3300 3300 3000 2600 2200 2000 1800
Max. flow In nmax qv L/min 59.4 59.4 84 117 156 200 252
in 1500 r/min 27 27 42 68 107 150 210
(¦¤p=280bar) in nmax Pmax Kw 27.7 27.7 39 55 73 93 118
Max. power in 1500 r/min 12.6 12.6 20 32 50 70 98
(¦¤p=280bar) in Vg max Tmax Nm 80.1 80.1 125 200 316 445 623
Max. torque
Weight m Kg 12 12 15 21 33 45

60

Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft StructureFast Control Response Inline Axial Piston Pump A10V With Through - Shaft StructureFast Control Response Inline Axial Piston Pump A10V With Through - Shaft StructureFast Control Response Inline Axial Piston Pump A10V With Through - Shaft StructureFast Control Response Inline Axial Piston Pump A10V With Through - Shaft StructureFast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure

Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure

Rexroth A2F/A2FO/A2FM/A10V/A10VG45/A10VG63/A10VSO/A4V/A4VSO/A6V/A6VM/A7V/A7VO/A8V/A8VO/A11V/A11VO bomba hydraulic pump

Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure

A2F

Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure

A4VSO

Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure

A6VM

Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure

A7V

Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure

Rexroth HMCR series

Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure

Poclain MS/MK series

Fast Control Response Inline Axial Piston Pump A10V With Through - Shaft Structure

Appliation:

Our pumps are mainly used for construction machinery, geological drilling equipment, special vehicles,mining machinery, lifting and transporting equipment, cranes, ship machinery, agricultural and forestry machinery, and so on.
