Specifications
Brand Name :
PENAD
Model Number :
30PDCT
Certification :
ISO, CE/TUV
Place of Origin :
China
MOQ :
1set
Supply Ability :
3000/SET/YEAR
Delivery Time :
3-4 working days
Packaging Details :
Carton
Material :
Aluminium-Titanium alloy
Color :
Red, silver, blue, black
OEM :
Available
Brand :
Penad
Model :
30PDCT
Torque :
4459-44593N.m
Suitable nut size :
160-175mm
Origin :
China
Description

4459-44593N.m Hexagon cassette type hydraulic torque wrench for mining , power plant

Application field:

Hydraulic wrenches are widely used. Hydraulic torque wrench is an important tool for the installation and disassembly of large-sized bolts in the construction, maintenance and repair of shipbuilding, petrochemical, wind power, hydropower, thermoelectric, mining, machinery, steel mills, rubber, pipelines and other industries. There is no substitute for other tools, which is not only convenient to use, but also provides very accurate torque, and the torque repetition accuracy reaches about ±3 %.

Characters:

1. Low profile hydraulic torque wrench manufacturer, high quality with good performance.

2. High strengthen aluminium-titanium alloy body.

3. 700 bar maximum working pressure, Repeat accuracy ±3%

4. 360° multi-positional swivel quick release couplings

5. Can work with the high resistance sockets, suitable for more size of nuts.

Hydraulic Hexagon Cassette Torque Wrench , Nuts And Bolts Power Tools

Product Drawings:

Hydraulic Hexagon Cassette Torque Wrench , Nuts And Bolts Power Tools

Technical Data:

SELECTION CHART OF PDCT SERIES ULTRO THIN HOLLOW HYDRAULIC WRENCH
MODEL 2PDCT 4PDCT 8PDCT 14PDCT 18PDCT 30PDCT 50PDCT
TORQUE(N.m) 232-2328 241-2414 585-5858 647-6474 1094-10941 1177-11774 1852-18521 2695-26958 488-41882 4459-44593 7081-70813
NUT SIZE(S) 19-55 60 34-65 70-80 41-95 100-105 50-117 65-130 110-155 160-175 105-225
POWER HEAD WEIGHT(KG) 0.9 0.9 1.7 1.7 3 3.1 4.6 6.5 10.4 10.4 35.5
WORKING HEAD WEIGHT(KG) 1.5 1.5 3.4 3.4 6.3 6.3 11.4 14.3 20.5 20.5 42
L 196 196 258 263 30 311 360 388 430 441 493
H1 126 129 163 173 192 201 225 264 303 315 328
H2 102 105 136 146 168 177 2045 231 272 285 295
W1 32 32 42 42 53 53 64 71 85 85 102
W2 51 51 66 66 83 83 99 109 131 131 160

FAQ:

1, How to choose the correct model?

a. according to your required max. torque force.

b. your nuts size.

2. Package

Usually, packed in metal case, then in carton, easily to move, protect the wrench from damage.

3. Warranty.

We provide one year quality warranty from the shipping date. except the artificial damage

4. Delivery time

Usually we have stock, can be send out 2-3 working days, big quantity, we need to confirm the delivery time.

Construction site:

Our hydraulic torque wrenches are wildely used in mining , wind power plant , petroleum , chemical and many other field

Hydraulic Hexagon Cassette Torque Wrench , Nuts And Bolts Power Tools
