Static Silicon Brushless Kaplan Vertical Hydro Turbine 1200kw 50m Water Head
Static Silicon Brushless Kaplan Vertical Hydro Turbine 1200kw 50m Water Head
Static Silicon Brushless Kaplan Vertical Hydro Turbine 1200kw 50m Water Head
Static Silicon Brushless Kaplan Vertical Hydro Turbine 1200kw 50m Water Head
Static Silicon Brushless Kaplan Vertical Hydro Turbine 1200kw 50m Water Head
Static Silicon Brushless Kaplan Vertical Hydro Turbine 1200kw 50m Water Head
Specifications
Brand Name :
Wawushan
Model Number :
ZDJP-058
Certification :
ISO9000
Place of Origin :
China
MOQ :
1
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
1+unit+4 months
Delivery Time :
180 wordking days
Packaging Details :
plywood
Layout :
vertical
runner blade :
fixed
runner diameter :
1.2 m
Water head :
50m
Water flow :
3.06 m³/s
Cpacity :
1200 KW
Description

Hydro Electrical Generator Kaplan Hydro Turbine Generator 1200kw​

Hydro turbine generator is driven directly or indirectly by hydro turbine. The rotating speed is less than 1500r/min, with horizontal and vertical arrangement. Excitation mode with brushless and static silicon type. Components including stator, rotor, base frame, bearing, excitation motor or collecting ring. The outlet voltage from 400V to 13.8KV, and frequency could be 50Hz or 60Hz, output from 50Kw to 50Mw. Our generator is high efficiency, reliable, manufacture and tests all follow related IEC standards.

Ø Frequency: 50 or 60Hz;

Ø Voltage scope: 0.38-13.8KV;

Ø Arrangement: vertical and horizontal;

Ø Speed scope: 93.75-1500r/m;

Ø Power factor: 0.8 – 1;

Ø Insulation Level: F/F;

Ø Output scope: 50Kw- 50Mw

Place of Origin: Sichuan, China
Brand Name: Customized
Warranty: 1 year
Application: Hydropower Plant
Certificate: ISO9001
Lifetime 35 years

Static Silicon Brushless Kaplan Vertical Hydro Turbine 1200kw 50m Water Head

Static Silicon Brushless Kaplan Vertical Hydro Turbine 1200kw 50m Water HeadStatic Silicon Brushless Kaplan Vertical Hydro Turbine 1200kw 50m Water Head

Static Silicon Brushless Kaplan Vertical Hydro Turbine 1200kw 50m Water Head

Static Silicon Brushless Kaplan Vertical Hydro Turbine 1200kw 50m Water Head

Static Silicon Brushless Kaplan Vertical Hydro Turbine 1200kw 50m Water HeadStatic Silicon Brushless Kaplan Vertical Hydro Turbine 1200kw 50m Water Head
