Specifications
Brand Name :
RENOWELL
Model Number :
T6CC T6CCM T6CCZ T6CCW T6CCP
Certification :
CE, ISO9001
Place of Origin :
CHINA
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5000 UNITS / MONTH
Delivery Time :
2-5 Working days for sample Order
Packaging Details :
Wooden case
Condition :
New Aftermarket Replacement
Structure Type :
Hydraulic Vane Pump
Standard :
Standard as original
Power :
Hydraulic
Pressure :
High Pressure
Noise :
Low Noise
pump model :
T6CC, T6CCM, T6CCW, T6CCZ, T6CCP
Max Pressure :
28Mpa
Max Rotation Speed :
2800 r/min
Application :
engineering machinery, rubber and plastics machinery etc
Warranty :
1 year
Sample Order :
Acceptable
Description

T6CCZ B20 B12 WL** A111 Double Vane Pump T6CCZ Hydraulic Pump for sale

T6CC PUMP TYPE:

T6CC, T6CCM, T6CCW, T6CCZ, T6CCP


T6CC, T6CCM, T6CCW, T6CCZ, T6CCP High pressure and high performance dowel pin type vane pumps are widely used for plastic machinery, casting machinery, metal machinery, pressing machinery, refining machinery, construction machinery, marine-Machinery.

Features

1. With dowel pin vane structure, it can work in high pressure, low noise and long lifetime.
2. This vane pump can fit side viscosity hydraulic medium, and be started at low temperature and work at high temperature.
3. As the vane pump adopts bilabial structure vane, it has high oil polution resistance and wide speed scope.

4. All parts can be replaced with the original , including cartridge kits, Shafts, Seals, Bearings and other parts.

T6 T7 Double Pump Exploded View
NO. Part Low Noise Industrial Hydraulic Pump High Performance Dowel Pin Type
1 Shaft
2 Straight Key
3 Hexagon head bolt
4 Front cover
5 Shaft Seal
6 Cir clip for shaft
7 Ball Bearing
8 Cir clip for hole
9 Rectangle seal ring
10 Front Cartridge
11 Middle body
12 Rear Cartridge
13 Rectangle seal ring
14 Rear Cover
15 Hexagon head bolt

Technic data

T6CC -25 -17 -1 R 2 -C 1 10
Series Flow Code Flow Code Shaft type Rotation Outlet position Design No. Sealing level Port Dimensions
T7BB T7BBS B03, B04, B05, B06, B07, B08, B10, B12, B15 B03, B04, B05, B06, B07, B08, B10, B12, B15 See of shaft code R or L See pictures C 1-S1 Nitril rubber 00 or 01 See Installation dimensions
5-S5 Fluono or Viton rubber
T67CB B03, B05, B06, B08, B10, B12, B14, B17, B20, B22, B25, B28, B31 B03, B04, B05, B06, B07, B08, B10, B12, B15 No option
T6CC B03, B05, B06, B08, B10, B12, B14, B17, B20, B22, B25, B28, B31 B03, B05, B06, B08, B10, B12, B14, B17, B20, B22, B25, B28, B31 00, 01, 10,11 See Installation dimensions
T67DB B14, B17, B20, B22, B24, B28, B31, B35, B38, B42, B45, B50, B61 B03, B04, B05, B06, B07, B08, B10, B12, B15
T6DC B14, B17, B20, B22, B24, B28, B31, B35, B38, B42, B45, B50, B61 B03, B05, B06, B08, B10, B12, B14, B17, B20, B22, B25, B28, B31
T67EB B42, B45, B50, B52, B57, B62, B66, B72, B85 B03, B04, B05, B06, B07, B08, B10, B12, B15
T6EC B42, B45, B50, B52, B57, B62, B66, B72, B85 B03, B05, B06, B08, B10, B12, B14, B17, B20, B22, B25, B28, B31
T6ED B42, B45, B50, B52, B57, B62, B66, B72, B85 B14, B17, B20, B22, B24, B28, B31, B35, B38, B42, B45, B50, B61
Application
Low Noise Industrial Hydraulic Pump High Performance Dowel Pin Type
Products Show:
Low Noise Industrial Hydraulic Pump High Performance Dowel Pin Type
Low Noise Industrial Hydraulic Pump High Performance Dowel Pin TypeLow Noise Industrial Hydraulic Pump High Performance Dowel Pin Type
Workshop & assembly processing
Suzhou Renowell Hydraulic Pump Co.,Ltd specialize in research and development, production and sales of high-end
hydraulic pump products. The main products of our company are: Dennison T6, T7 series vane pumps; Vickers V, VQ
series, V10, V20 series vane pumps; Tokimec SQP series vane pumps; Yuken PV2R series hydraulic vane pumps; PGH4,
PGH5 series gear pumps; high pressure piston pumps and parts.
Low Noise Industrial Hydraulic Pump High Performance Dowel Pin TypeLow Noise Industrial Hydraulic Pump High Performance Dowel Pin TypeLow Noise Industrial Hydraulic Pump High Performance Dowel Pin Type
Exhibition Show
Low Noise Industrial Hydraulic Pump High Performance Dowel Pin TypeLow Noise Industrial Hydraulic Pump High Performance Dowel Pin Type
Certiicate
Low Noise Industrial Hydraulic Pump High Performance Dowel Pin Type
