Backhoe Hydraulic Jack Hammer 350 BPM - 700 BPM Excavator Mounted Jackhammer
Backhoe Hydraulic Jack Hammer 350 BPM - 700 BPM Excavator Mounted Jackhammer
Specifications
Brand Name :
HANYUN
Model Number :
HY100
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable price
Payment Terms :
L/C, T/T
Supply Ability :
10,000 sets per year
Delivery Time :
3-15working days
Packaging Details :
plywood box or other exported packages
Item :
Skid Steer Concrete Breaker
Chisels materials :
40crmo
Breaker chisels diameter :
100 mm
Breaker shell materials :
High strength steel plate
Working Purpose :
Building demolition and concrete breaking
Applicable backhoe and skid steers :
world-famous brand
Applicable skid steers :
11-16 Ton
Color :
Yellow, blue, red and other colors
Description

Backhoe And Skid Steer Concrete Breaker Attachment 350-700BPM Striking Frequency

(1) About skid steer concrete breaker

Skid steer concrete breaker from Hanyun has very reasonable design and compact structure. To ensure a

perfect match with your skid steer loaders, we have various models for your selection

(2) How to select one suitable skid steer concrete breaker?

For effective and efficient crushing of rocks, one suitable concrete breaker must be selected before working.

1. Firstly we have to consider the skid steer model and its hydraulic power, because the rock breaker hammer is

customized to suit the excavator;

2. Secondly the skid steer working envrionment has to be considered. Rock breaker hammer chisels head types

(flat head, pointed head, conical head, round head)will be selected according to that;

3. Finally good quality concrete breaker will be selected for a long service life and less failure rate.

Rock breaker hammers made by Hanyun will be a great choice with good reputation from customers

(3) Main Technical Parameters on skid steer concrete breaker

Model HY75 HY85 HY100 HY120
Breaker shell weight (KGS) 200 400 450 500
Total weight(KG) 345 493 736 1374
Size (MM) 1140*370*740 1270*370*800 1340*430*970 1475*530*1000
Driving oil pressure (KG/CM2) 120-150 130-160 150-170 150-170
Hydraulic oil flow (L/MIN) 50-90 60-100 80-110 90-120
Striking frequency (BPM) 400-800 400-800 350-700 350-650
Soft hose diameter (INCH) 1/2 3/4 3/4 3/4
Drill rod diameter (MM) 75 85 100 120
Drill rod weight (KG) 22 48 50 120
Applicable carrier weight (T) 6-9 7-14 11-16 12-18

Backhoe Hydraulic Jack Hammer 350 BPM - 700 BPM Excavator Mounted Jackhammer

(4) About packing and transportation

About packing: Usually the skid steer concrete breaker is packed with plastic film firstly, then packed them

with plywood box or plywood pallets before loading them into container

About transportation: the popular transportation method is by sea, by air, by railway and by road

Backhoe Hydraulic Jack Hammer 350 BPM - 700 BPM Excavator Mounted Jackhammer
