9 Ton Excavator 40CRMO Chisels Hydraulic Jack Hammer For Skid Loader Pin Breaker
9 Ton Excavator 40CRMO Chisels Hydraulic Jack Hammer For Skid Loader Pin Breaker
Specifications
Brand Name :
HANYUN
Model Number :
HY75
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable price
Payment Terms :
L/C, T/T
Supply Ability :
10,000 sets per year
Delivery Time :
3-15working days
Packaging Details :
plywood box or other exported packages
Item :
Hydraulic Jack Hammer
Chisels materials :
40CRMO, 42CRNIMO. 42CRMO
Breaker chisels diameter :
75 mm
Breaker shell materials :
High strength steel plate
Working Purpose :
concrete breaking
Applicable excavator :
world-famous brand
Applicable excavator weight :
6-9 Ton
Color :
Yellow, blue, red and other colors
Description

Hydraulic Jack Hammer Hard Pin Breaker Attachments For Breaking Concrete

(1) How many models of hydraulic jack hammers Hanyun Have?

Hydraulic jack hammers from Hanyun have different models to suit different excavators, loaders, skid steers and

backhoes.

About 14 popular models are produced in Hanyun, customized model also supported

Model Breaker chisel diameter (mm) Applicable excavator weight (T)
HY53 53 1.2-3
HY68 68 2-4
HY75 75 6-9
HY85 85 7-14
HY100 100 11-16
HY120 120 12-18
HY135 135 18-23
HY140 140 19-25
HY155 155 25-30
HY165 165 30-36
HY175 175 36-42
HY185 185 42-48
HY195 195 48-55

(2) Main Technical Parameters on rock breaker hammer

Model HY75 HY85 HY100 HY120
Breaker shell weight (KGS) 200 400 450 500
Total weight(KG) 345 493 736 1374
Size (MM) 1140*370*740 1270*370*800 1340*430*970 1475*530*1000
Driving oil pressure (KG/CM2) 120-150 130-160 150-170 150-170
Hydraulic oil flow (L/MIN) 50-90 60-100 80-110 90-120
Striking frequency (BPM) 400-800 400-800 350-700 350-650
Soft hose diameter (INCH) 1/2 3/4 3/4 3/4
Drill rod diameter (MM) 75 85 100 120
Drill rod weight (KG) 22 48 50 120
Applicable carrier weight (T) 6-9 7-14 11-16 12-18

(3) What are advantages of Rock breaker hammer?

Hydraulic breaking hammer is used to break stones or rocks in mining projects, it has below features:

1. Simple and compact structure for easy operation and maintenance;

2. Light-weight design for convenient using;

3. Strong striking force;

4. High anti-striking strength;

5. Long service life;

6. High working efficiency

9 Ton Excavator 40CRMO Chisels Hydraulic Jack Hammer For Skid Loader Pin Breaker

(4) Hanyun History

20 years ago, there had not one company called HANYUN in China

There just had one small street store for selling hydraulic hammers and other excavator attachments from other factories.

And totally 3 employees there, including the boss.

10 years ago, our boss established one company called Hanyun Construction Machinery Co., Ltd, which is one direct factory for manufacturing hydraulic hammers and breaker chisels, with 85 workers.

Till today, at the end of 2021, HANYUN already have 3 factories with total employees 210, one factory for fabricating hydraulic hammer shells, one for breaker chisels and the other one for chisels cylinders. And the output and sales volume ranks top 3 in China market.

Why Hanyun could grow up from one small store to one professional group company?

The answer is:

  • Customers are willing to trust Hanyun and to give valuable advice, positive or negative;
  • Hanyun people are very happy to accept criticism and keep improving our products quality;
  • Cherish trust from customers and do better.

Trust is extremely expensive. In the coming future, Hanyun will work harder to feedback more to our customers.

9 Ton Excavator 40CRMO Chisels Hydraulic Jack Hammer For Skid Loader Pin Breaker
