SOOSAN Hydraulic Breaker Chisels Rock Wedge 135mm Rod Bits Impact Part
SOOSAN Hydraulic Breaker Chisels Rock Wedge 135mm Rod Bits Impact Part
SOOSAN Hydraulic Breaker Chisels Rock Wedge 135mm Rod Bits Impact Part
SOOSAN Hydraulic Breaker Chisels Rock Wedge 135mm Rod Bits Impact Part
Specifications
Brand Name :
HANYUN
Model Number :
HYQG135
Place of Origin :
China
MOQ :
5-10 pieces
Price :
Negotiable
Payment Terms :
L/C, T/T, D/A, D/P
Supply Ability :
100,000 pieces per year
Delivery Time :
3-8 working days
Packaging Details :
pallet or wooden box
Item :
Hydraulic Hammer Chisels
Chisels materials :
40CRMO,42CRMO
Breaker chisel diameter :
135mm
Length :
1300mm
Steel type :
Hot rolled steel
Excavator used :
19-23t
Nearest port :
Qingdao port, Tianjin port, Shanghai port
Chisel head :
Wedge chisel
Description

SOOSAN STANLEY NPK Hydraulic Hammer Chisels Impact Part Wedge Chisel

(1) What are the right methods to install hydraulic hammer chisels?

The methods of installing hydraulic hammer chisels are as below:

1. Put the hydraulic breaker hammer on the ground first, preferably with two sleepers underneath

2. Buckle off the plug on the side of the stop pin

3. Use a thin iron rod to smash out the stop pin

4. The flat pin can be taken out when the stop pin is removed

5. Pull out the old drill rod directly

6. Put some butter on the head of the new drill rod and insert it into the bushing.

7. Then install flat pins, stop pins and plugs in sequence.

8. Finally, fill some butter.

(2) Main specifications of hydraulic breaker hammer chisels

Brand HANYUN
Breaker chisel model HYQG135
Chisel diameter 135mm
Chisel weight 125kgs
Chisel length 1300mm or customized length
Applicable carrier weight 19-23T

SOOSAN Hydraulic Breaker Chisels Rock Wedge 135mm Rod Bits Impact Part

(3) What are advantages for Hydraulic breaker hammer chisels from Hanyun?

Hanyun is a leading manufacturer of hydraulic hammer chisesls from China, we produce and export large

quantity of breaker drill rods and hydraulic breaker hammers each year, main features are as below:

1. High-strength wear-resistant round steel 40CRMO/42CRMO;

2. Advanced self-own heat treatment and cooling technology. Using segmented quenching, it is not easy to

break when using steel drill rod

3. Stable quality and strong crushing force, the hardness of the hammer tip is about 55 degrees, the hardness

of the flat pin is about 48 degrees, and the hardness of the tail is about 45 degrees;

4. Multi-purpose with one hammer, economical and efficient, long service time;

5. Fast delivery in batches, support customization


SOOSAN Hydraulic Breaker Chisels Rock Wedge 135mm Rod Bits Impact Part
