40CRMO Hydraulic Breaker Hammer DH170 120mm Chisel Jack Hammer For Mini Excavator
40CRMO Hydraulic Breaker Hammer DH170 120mm Chisel Jack Hammer For Mini Excavator
Specifications
Brand Name :
HANYUN
Model Number :
HY120
Certification :
ISO/CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, , T/T
Supply Ability :
5000 sets per year
Delivery Time :
5-15 working days
Packaging Details :
fumigation-free plywood box/ exported packages
Item 1 :
Hammer Hydraulic Breaker
Item 2 :
Rock Hammers For Excavators
Breaker chisel diameter :
120mm
Breaker chisel name :
hydraulic drill rods
Breaker chisel materials :
40CRMO/42CRMO
Near port :
Qingdao/Tianjin/Shanghai Port
Applicable excavator :
CAT315DL
Applicable Doosan excavator :
SOLAR170/DH170
Description

Hammer Hydraulic Breaker Rock Hammers For Excavators And Skid Steer Loader

(1) About Hammer hydraulic breaker

Hammer hydraulic breaker also called as rock hammers for excavators, work as attachments of excavators, skid steer,

backhoe and crawler loaders to break rocks in mining and quarry projects

(2) Recommended products on hammer hydraulic breaker from Hanyun

Hydraulic breaker Hydraulic breaker hammer
Hydraulic excavator hammer Hydraulic jack hammer
Hydraulic breaker chisels Hydraulic drill rods
Excavator attachments Hydraulic demolition hammer
Skid steer breaker hammer Hydraulic hammer for excavator

(3) What parts will be included as we deliver one hammer hydraulic breaker?

As delivery, one complete hammer hydraulic breaker will be sent for easy and convenient using in the worksite.

Main parts are as below:

1. Hydraulic rock breaker *1 set

2. Breaker chisels 75mm* 2 pieces

3. Soft hose 0.5mm * 2 pieces

4. Nitrogen gas bottle and meter *1 set

5. Tool set* 1 set

(4) Main technical parameters on hammer hydraulic breaker

Model SY135C-8, SY155H CAT315DL/DOOSAN SOLAR170
Breaker shell weight (KGS) 450 500
Total weight(KG) 736 1374
Size (MM) 1340*430*970 1475*530*1000
Driving oil pressure (KG/CM2) 150-170 150-170
Hydraulic oil flow (L/MIN) 80-110 90-120
Striking frequency (BPM) 350-700 350-650
Soft hose diameter (INCH) 3/4 3/4
Drill rod diameter (MM) 100 120
Drill rod weight (KG) 50 120
Applicable carrier weight (T) 11-16 12-18

(5) About packing and transportation of hydraulic rock breaker

Packing: Fumigation-free plywood box or pallet packing

Transportation: Sea transportation by container

(6) Advantages of Hanyun

  • Top 3 output and sales volume for breaker chisels in China;
  • High strength alloy steel 40CrMo/42CrMo used, longer service life;
  • High-end imported processing equipment like Doosan and powerful hardware facilities realize automated production;
  • Excellent heat treatment technology has superior durability.
  • Large output, high quality, fast delivery;
  • Complete models;
  • Perfect 7-person after-sales service team;
  • Strict control of raw materials purchasing and processing, implement Ultrasonic Testing before, during and after production.
