JIS Standard EN36A Forged Steel Round Bar , Alloy Steel Bar OD 80mm -1200mm
JIS Standard EN36A Forged Steel Round Bar , Alloy Steel Bar OD 80mm -1200mm
JIS Standard EN36A Forged Steel Round Bar , Alloy Steel Bar OD 80mm -1200mm
JIS Standard EN36A Forged Steel Round Bar , Alloy Steel Bar OD 80mm -1200mm
Specifications
Brand Name :
UST
Model Number :
DIA 80-1200mm
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
MOQ: 2-3 ton
Price :
FOB USD 1000- 1500/ton
Supply Ability :
1500 ton/month
Delivery Time :
Within 4-6 weeks
Packaging Details :
Plastic plugs in both ends, Hexagonal bundles of max 2,000kg with several steel strips, Two tags on each bundle, Wrapped in waterproof paper, PVC sleeve, and sackcloth with several steel strips.
t(optional) Ultrasonic test :
According to SEP 1921-84 3C/c
Type: :
Alloy Steel Bar
Standard: :
AISI, ASTM, BS, DIN, GB, JIS
shape :
Round Section
Description

JIS Standard EN36A Forged Steel Round Bar , Alloy Steel Bar OD 80mm -1200mm

APPLICATIONS:

Heavy Duty Bushings, Collets, Conveyor Pins, Heavy Duty Gears, King Pins, Ring Gears, Sprockets, Shafts, heavy-duty gears, collets etc. Or can be used for high tensile applications uncarburised but through hardened and tempered.

Related Specifications

Australia AS 1444-1996-X3312/X3312H

Germany W.Nr 1.5752 DIN 14NiCr14

Great Britain BS970: PART 3: 1991 655 M13

BS970: 1955 - EN36A

EN10084-1998 1.5752 15NiCr13 or

1.5752H 15NiCr13H

Japan JISG 4052 SNC815H

JISG 4102 SNC815

U.S.A. SAE 3310 9310

AISI E3310 E9310

UNS G33106/G93106

Chemical Composition(%):

Material EN36
Chemical Composition Mechanical Properties(In Quenched & Tempered State)
C 0.1-0.17 Tensile strength(MPA) ≥930
Si 0.17-0.37 Yield strength (MPA) ≥685
Mn 0.30-0.60 Elongation(δ5/%) 11
Cr 0.60-0.90 Reduction in Area (ψ/%) 55
Mo Impact (J)
P ≤0.035

Hardness
S ≤0.035
Cu
Ni 2.75-3.15

Process: EAF+LF+VOD+Forged+Heat Treatment(optional)

SIZE RANGE:

Round:

Hot Forged: 80mm -1200mm

SURFACE FINISHES:

Black, Peeled (K12), Turned & Polished (H10, H11)

Test: Ultrasonic test according to SEP 1921-84 3C/c

Certificate of Quality: issued in English, in addition the normal terms, production process, the mechanical property (yield strength, tensile strength, elongation and hardness), forged ratio, UT test result, Grain size, heat treatment methods and the sample of is shown on the Certificate of Quality.

Marking: Heat No. will be cold stamped and Steel grade, diameter (mm), length (mm), and the manufacturer LOGO and weight (kg) is painted

JIS Standard EN36A Forged Steel Round Bar , Alloy Steel Bar OD 80mm -1200mm
