SAE 3310 Round Steel Bar Hot Rolled Technical 0.17%-0.23% Chemical Composition
SAE 3310 Round Steel Bar Hot Rolled Technical 0.17%-0.23% Chemical Composition
SAE 3310 Round Steel Bar Hot Rolled Technical 0.17%-0.23% Chemical Composition
SAE 3310 Round Steel Bar Hot Rolled Technical 0.17%-0.23% Chemical Composition
SAE 3310 Round Steel Bar Hot Rolled Technical 0.17%-0.23% Chemical Composition
SAE 3310 Round Steel Bar Hot Rolled Technical 0.17%-0.23% Chemical Composition
SAE 3310 Round Steel Bar Hot Rolled Technical 0.17%-0.23% Chemical Composition
SAE 3310 Round Steel Bar Hot Rolled Technical 0.17%-0.23% Chemical Composition
Specifications
Brand Name :
Unite Steel
Model Number :
Dia: 10-350mmm
Certification :
ISO/MTC/BV/SGS
Place of Origin :
China
MOQ :
MOQ :2-3 Ton
Price :
USD 600-900 per Ton
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
3000 Ton per Month
Delivery Time :
Within 15-45 days
Packaging Details :
Stanard seaworthy packing or as your request .
Product name :
SAE 3310 Hot Rolled Steel Bar , Modified Alloy Steel Round Bars , Delivery condtion QT
Material grade :
SAE 3310
Delievry condition :
Annealed/hot rolled/cold drawn/quenched & tempered
Surface :
Black/machined/peeled/polished/turned
Shape :
Round section
Process :
EAF+LF+VOD+Rolled+Heat Treatment(optional)
Ultrasonic inspection :
100% ultrasonic inspection for any inperfections or based on the customer's requirement
Certificate :
ISO/MTC/BV/SGS
Description

SAE 3310 Hot Rolled Steel Bar , Modified Alloy Steel Round Bars , Delivery condtion QT

Steel group: Case hardening steel

Application: Highly stressed large sized components for aircraft and truck construction, and for general engineering purposes, e.g. gear wheels, cranks hafts, heavy-duty gear shafts.

SAE 3310 Round Steel Bar Hot Rolled Technical 0.17%-0.23% Chemical Composition

Features: 20Cr2Ni4 is high intension of alloy cementation steel ,has excellent comprehensive mechanical property. It's hardenability and obdurability higher than 12CrNi3. It's excellent forgeability.

Related specifications:

Germany W.Nr 1.5752 DIN 14NiCr14
Great Britain BS970 – Part 3 – 1991 655 M13
BS970 1955 EN36A
GOST G55H13, G55M13
Japan JIS G 4052 SNC815H
JIS G 4102 SNC815
U.S.A. SAE 3310 9310
AISI E 3310 E9310
France 12NC15, 14NC12
Australia AS 1444-2007 – X3312/X3312H
UNS G33106/G93106

Color of end: SIGNAL RED END

Quality Standard:
EN 10277 - 4 : 2008 Bright steel products. Technical delivery conditions. Case hardening steels
EN 10084 : 2008 Case hardening steels. Technical delivery conditions

Chemical Composition(%):

C Si Mn Cr S P Ni
0.17-0.23 0.17-0.23 0.30-0.60 1.25-1.65 0.04max 0.04max 3.25-3.65

Process: EAF+LF+VOD+Rolled+Heat Treatment(optional)

SAE 3310 Round Steel Bar Hot Rolled Technical 0.17%-0.23% Chemical Composition

SIZE RANGE:
Round:
Hot Rolled: 10mm –350mm


SURFACE FINISHES:
Black, Peeled (K12), Cold Drawn, Turned & Polished (H10, H11), Precision Ground (H9, H8)

Ultrasonic test: According to SEP 1921-84 3C/c

Range of application and heat treatment :
Cementation steel : gear wheels , crankshafts , gear components
Hardening : 830 - 850 °C (oil) Soft annealing : 620 - 650 °C Normalising : 830 - 860 °C

Certificate of Quality: issued in English, in addition the normal terms, production process, the mechanical property (yield strength, tensile strength, elongation and hardness), forged ratio, UT test result, Grain size, heat treatment methods and the sample of is shown on the Certificate of Quality.

Marking: Heat No. will be cold stamped and Steel grade, diameter (mm), length (mm), and the manufacturer LOGO and weight (kg) is painted

SAE 3310 Round Steel Bar Hot Rolled Technical 0.17%-0.23% Chemical Composition

SAE 3310 Round Steel Bar Hot Rolled Technical 0.17%-0.23% Chemical Composition
