AISI 3310 Alloy Steel Round Bar With Black / Peeled / Cold Drawn , Size 10-350mm
AISI 3310 Alloy Steel Round Bar With Black / Peeled / Cold Drawn , Size 10-350mm
AISI 3310 Alloy Steel Round Bar With Black / Peeled / Cold Drawn , Size 10-350mm
AISI 3310 Alloy Steel Round Bar With Black / Peeled / Cold Drawn , Size 10-350mm
Specifications
Brand Name :
Unite Steel
Model Number :
Dia : 10-350mm
Certification :
MTC/SGS/BV/ISO
Place of Origin :
China
MOQ :
MOQ : 2-3 Ton
Price :
USD700-1000 Ton
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
3000 Ton per Month
Delivery Time :
Within 15-45 days
Packaging Details :
Standard seaworthy packing or as your request
Product name :
AISI 3310 Hot Rolled Steel Bar ,Alloy steel round bar with black/peeled/cold drawn,size 10-350mm
Material grade :
AISI 3310
Delivery condition :
Annealed/hot rolled/cold drawn/quenched & tempered
Surface :
Black/machined/peeled/polished/turned
Shape :
Round section
Process :
EAF/LD+LF+VD+INGOT+HOT ROLLED/FORGED+Spheroidizing Annealing+UT+CUT
Ultrasonic test :
according to SEP 1921-84 3C/c
Certificate :
MTC/SGS/BV/ISO
Description

AISI 3310 Alloy Steel Round Bar With Black / Peeled / Cold Drawn , Size 10-350mm

1.APPLICATIONS:

Heavy Duty Bushings, Collets, Conveyor Pins, Heavy Duty Gears, King Pins, Ring Gears, Sprockets, Shafts, heavy-duty gears, collets etc. Or can be used for high tensile applications uncarburised but through hardened and tempered.

AISI 3310 Alloy Steel Round Bar With Black / Peeled / Cold Drawn , Size 10-350mm

2.Related Specifications

Australia AS 1444-1996-X3312/X3312H

Germany W.Nr 1.5752 DIN 14NiCr14

Great Britain BS970: PART 3: 1991 655 M13

BS970: 1955 - EN36A

EN10084-1998 1.5752 15NiCr13 or

1.5752H 15NiCr13H

Japan JISG 4052 SNC815H

JISG 4102 SNC815

U.S.A. SAE 3310 9310

AISI E3310 E9310

UNS G33106/G93106

3.Chemical Composition(%):

Carbon 0.10-0.16

Silicon 0.10-0.40

Manganese 0.35-0.60

Nickel 3.00-3.75

Chromium 0.70-1.00

Phosphorous 0.04 max

Sulphur 0.04 maX

4.Process: EAF+LF+VOD+Rolled+Heat Treatment(optional)

AISI 3310 Alloy Steel Round Bar With Black / Peeled / Cold Drawn , Size 10-350mm

5.SIZE RANGE:

Round:

Hot Rolled: Dia 10-350mm

6.SURFACE FINISHES:

Black, Peeled (K12), Cold Drawn, Turned & Polished (H10, H11), Precision Ground (H9, H8)

7.Test: Ultrasonic test according to SEP 1921-84

8.Certificate of Quality: issued in English, in addition the normal terms, production process, the mechanical property (yield strength, tensile strength, elongation and hardness), forged ratio, UT test result, Grain size, heat treatment methods and the sample of is shown on the Certificate of Quality.

9.Marking: Heat No. will be cold stamped and Steel grade, diameter (mm), length (mm), and the manufacturer LOGO and weight (kg) is painted
