Excavator Aluminum Gear Pump PV2R3-136 Color Same As Photo High Efficiency
Excavator Aluminum Gear Pump PV2R3-136 Color Same As Photo High Efficiency
Specifications
Brand Name :
KE HAO
Model Number :
PV2R3-136
Certifiion :
OEM
Place of Origin :
CHINA
MOQ :
1PC
Price :
Negotiated price
Payment Terms :
T/T, Western Union,Paypal
Supply Ability :
500 pieces per month
Delivery Time :
About 1-6 Days After Receiving The Deposit(Based On The Quantity)
Packaging Details :
Standard shipping package
Pressure :
High Medium Pressure
Power :
Hydraulic
Structure :
Gear Pump
Material :
Auminum Alloy
Color :
Same as photo
Warranty :
1 Year
Description

Full hydraulic Motor steering gear D7F Bulldozer Hydraulic Gear Pump PV2R3-136

What parameter you need to send us :

If you need the gear pump , please send us the pump picture and machine model , so we can check it easily .
If you need the hydraulic pump parts , you can send us the size of the piston shoe , so we can check the parts according to the piston shoe size , but it will be better if you send me the nameplate of the pump and pump picture .

Product Description:

Part No PV2R3-136
Condition New
OEM Yes(Made In China)
Material Aluminium Alloy
Spare Parts Special Designed wearable Spline,O-rings and bushes to last long service life
Characters No Oil Leak, Durable Shaft, Genuine Standard
Warranty One Year
Package Standard Export Wooden/Carton Cases
Weight About 0.5-1KG
Appliion Loader, Dozer, Excavator, Dumper, Grader, tractor, forklift truck etc.
Delivery Time About 1-6 Days After Receiving The Deposit(Based On The Quantity)
Price Factory Supply With Competitive Price
Quality Control All Pumps Will Be Tested And Double Checked Before Shipping To Make Sure What You Received Is Perfect.
Payment Flexible Payment As TT,Western Union,Paypal, Credit Card, Visa etc.

Excavator Aluminum Gear Pump PV2R3-136 Color Same As Photo High Efficiency

series gression
(mL/r)		 maximum pressure(MPA) speed(r / min) interiorinput power
(kW)
Special oil Antiwear oil Common oil Min. Max.
PV2R1-4 4.3 21 171.5 16 750 1800 2.1
PV2R1-6 6.5 3.2
PV2R1-8 8.5 4.5
PV2R1-10 10.8 5.4
PV2R1-12 12.8 6.1
PV2R1-14 14.5 6.9
PV2R1-17 16.2 7.9
PV2R1-19 20.1 9.6
PV2R1-23 22.5 10.5
PV2R1-25 25.3 12.5
PV2R1-28 29.6 14
PV2R1-31 32.3 16 16 15.5
PV2R2-26 25.3 21 17.5 14 600 1800 11.7
PV2R2-33 32.3 15.5
PV2R2-41 39.8 18.9
PV2R2-47 49.8 23.2
PV2R2-53 51.5 24
PV2R2-59 55.8 24.9
PV2R2-65 63.7 29.4
PV2R2-70 70.3 16 1200 31.6
PV2R2-79 78.1 35.7
PV2R2-85 82.7 37.5
PV2R3-52 51.5 21 17.5 14 600 1800 23.2
PV2R3-60 63.7 29.4
PV2R3-66 66.6 34.2
PV2R3-76 75.5 37.7
PV2R3-94 89.5 41.2
PV2R3-116 118 16 16 50
PV2R3-125 122.2 1200 59.9
PV2R3-136 136 66.7

Note : 1. When the pressure of the pump exceeds 16 MPa and the displacement is "4"6"8", the speed shall be greater than 145 or /min.

2. Reduce the negative pressure of the inlet when the single pump or double pump has a large displacement at high speed.

3 .Limit the maximum speed to 12oor/min when using synthetic hydraulic fluids and water containing hydraulic fluids.

4 .It is recommended to run at a speed of 1ooor/min with strict requirements for low noise.

5. Noise can be obtained under working conditions of 14 MPa and 12oor/min. Input power at 16 MPa and 1500r / min available under working conditions .

Instruction Manual of Installationand Operation for Gear Pump


In developed industry market, the spare parts of gear pump achieved sophistied . Therefore , check of clean oil with operation before using pump. The installation should be according to the ex-works technical documents of gear pump , and related specifiion of this manual , also the pump structure should be taken into consideration .
